Allen-Bradley SLC 500 | 1746-OB16E – 16-Point DC Output Module

Allen-Bradley 1746-OB16E SLC 500 Digital DC Output Module

Product Description

The Allen-Bradley 1746-OB16E is a 16-point digital DC output module for the SLC 500 series. It is designed for high-current applications with a wide operating voltage range of 10-30V DC. This module features electronic fusing and uses a convenient Removable Terminal Block (RTB) for easy wiring. It ensures reliable performance in industrial environments with robust noise immunity and a fast response time.

Key Features

16 outputs for versatile control.
High current capacity of 1A or 0.5A per point.
Wide voltage range (10-30V DC) for flexibility.
Electronically fused for protection.
Removable terminal block for easy installation.
Low heat dissipation for better efficiency.

Technical Data

Brand: Allen-Bradley / Rockwell Automation
Model: 1746-OB16E (Full Suffix Information)
Series: SLC 500
Module Type: Digital DC Output Module
Outputs: 16
Voltage Range: 10-30V DC Source
Current per Output: 1A or 0.5A
Total Module Current: 8A (9A at 30°C)
Backplane Current: 135 mA @ 5V DC
Response Time: 60ms ON, 2.5ms OFF
Operating Temperature: 0 to 60°C (32 to 140°F)
Heat Dissipation: 7.6W total

Installation Guide

Install the 1746-OB16E module in any available slot of a 1746 chassis. Use the Removable Terminal Block (RTB) for connecting field wiring. Ensure the operating environment is within the specified temperature and humidity range.

Compatibility

This module is compatible with all SLC 500 series processors and 1746 chassis. It works seamlessly with other SLC 500 I/O modules.

Packaging & Warranty

Package Includes: One 1746-OB16E module.
Warranty: 12 months limited warranty.
Shipping: We ship via FedEx, UPS, and DHL.
