Bently Nevada – 3300 XL 11 mm Extension Cable 330730-040-03-CN

Bently Nevada 3300 XL 11mm Extension Cable – Armored 4.0m (P/N: 330730-040-03-CN)

Premium Industrial Extension Cable

New factory-sealed armored cable for vibration monitoring systems. Designed for harsh environments with connector protector and stainless steel armor. Includes silicone tape for sealing. Made in USA.

Complete Specifications

• Brand: Bently Nevada
• Full P/N: 330730-040-03-CN
• Length: 4.0 meters (13.1 ft)
• Type: Armored triaxial cable
• Material: Gold-plated brass connectors
• Armor: AISI 302 SST with FEP jacket
• Capacitance: 69.9 pF/m typical
• DC Resistance: 1.0Ω ±0.25Ω (core), 0.3Ω ±0.1Ω (jacket)
• Weight: 0.56 kg

Installation Guide

• Max field wiring: 305 meters
• Wire gauge: 0.2-1.5 mm² (16-24 AWG)
• Tensile strength: 330N (probe), 270N (connectors)
• Use included silicone tape for sealing (avoid oil exposure)

Compatibility

Works with all 3300 XL 11mm probes. Supports FluidLoc option for oil containment. Compatible with systems requiring 5m or 9m total cable lengths.

Certifications

Country-specific approvals (CN option). Meets industrial safety standards.

Package & Warranty

• New in factory packaging
• Includes connector protector and silicone tape
• 12-month manufacturer warranty
• Shipping: FedEx, UPS, DHL worldwide

FAQ

Q: Is this compatible with FluidLoc systems?
A: Yes, can be ordered with FluidLoc option

Q: Minimum bend radius?
A: 25.4mm (1 inch) minimum

Q: Pressure rating?
A: Not pressure-rated – contact for special testing

Q: System length options?
A: 5m or 9m when combined with probes
