EL4034 Beckhoff EtherCAT Terminal 4-Channel Analog Output EL4034

EL4034 Beckhoff EtherCAT Terminal | 4-Channel Analog Output, ±10 V, 12 Bit

The EL4034 is a 4-channel analog output terminal from the Beckhoff EtherCAT range. It outputs voltage signals from -10 V to +10 V with 12-bit resolution. Each channel is electrically isolated. The output stages run from a 24 V DC supply through the power contacts. All four channels share a common ground potential. LEDs show the signal state of each channel. This terminal suits drives, valves, analog meters, and positioners that need a stable bipolar voltage command.

Technical Data

• Model: EL4034 (ES4034 with pluggable wiring)
• Brand: Beckhoff
• Series: EtherCAT Terminal, EL/ES series
• Module type: 4-channel analog output, voltage
• Connection technology: 2-wire, single-ended
• Number of outputs: 4
• Signal voltage: -10 to +10 V
• Resolution: 12 bit
• Output error: less than 0.1 percent of end value
• Load: above 5 kΩ, short-circuit proof
• Power supply: 24 V DC via power contacts
• Electrical isolation: 500 V, E-bus to signal voltage
• Conversion time: about 250 µs
• Distributed clocks: yes, precision below 1 µs
• Current consumption, power contacts: typical 25 mA
• Current consumption, E-bus: typical 140 mA
• Bit width in process image: 4 x 16 bit AO output
• Measurement range: -10 to +10 V output span
• Frequency response: set by 250 µs conversion time
• Sensitivity: 12-bit step size across the ±10 V span
• Linearity: output error under 0.1 percent of end value
• Temperature range: -25 to +60 °C operating, -40 to +85 °C storage
• Humidity: 95 percent relative, no condensation
• EMC immunity and emission: EN 61000-6-2 and EN 61000-6-4
• Vibration and shock: EN 60068-2-6 and EN 60068-2-27
• Protection rating: IP20
• Installation position: variable
• Weight: about 85 g

Special Functions

• Optional watchdog with user-specific output value and ramp
• User synchronization can be activated
• Common ground potential across all four channels
• LED signal state on every channel
• ES4034 version offers pluggable wiring

Housing and Wiring

• Design: compact terminal housing with signal LEDs
• ES version: terminal housing with pluggable wiring level
• Material: polycarbonate
• Dimensions: 12 mm x 100 mm x 68 mm
• Installation: 35 mm DIN rail per EN 60715, with lock
• Side by side mounting: double slot and key connection
• Marking: BZxxx series labels
• Wiring: spring actuation by screwdriver
• Solid conductor: 0.08 to 2.5 mm², AWG 28 to 14
• Stranded conductor: 0.08 to 2.5 mm², AWG 28 to 14
• With ferrule: 0.14 to 1.5 mm², AWG 26 to 16
• Stripping length: 8 to 9 mm
• Current load, power contacts: 10 A max

Approvals and Markings

• CE
• UL
• ATEX
• Ex marking: II 3 G Ex nA IIC T4 Gc

Ordering Information

• EL4034: EtherCAT Terminal, 4-channel analog output, voltage, ±10 V, 12 bit
• ES4034: same as EL4034, with pluggable wiring

Where the EL4034 Fits

• Servo and drive speed references
• Proportional valve control
• Analog positioner command signals
• Test benches and calibration rigs
• Process loops with bipolar voltage input
• Machine builders replacing older analog output cards

Oiltech Controls’s Insight

• The EL4034 is a workhorse for ±10 V command signals.
• 12-bit resolution suits most drive and valve loops.
• 250 µs conversion time covers standard motion tasks.
• Distributed clocks help when channels must update together.
• The ES4034 saves downtime when wiring must be swapped fast.

Oiltech Controls Review

• Engineers pick this terminal for clean bipolar output.
• Short-circuit proof outputs lower wiring risk.
• Common ground simplifies panel design.
• IP20 housing fits standard control cabinets.
• CE, UL, and ATEX markings cover many plant rules.

Why Buy From Oiltech Controls?

• More than 15 years in industrial automation spare parts.
• Shipment support to plants worldwide.
• Tested industrial surplus and refurbished options.
• 12-month warranty on eligible products.
• Technical check before every dispatch.
• Help with obsolete and hard-to-find control gear.

Shipping and Lead Time

• Dispatch within 24 to 28 hours for stock items.
• Shipping by FedEx, UPS, and DHL.
• Tracking number sent after dispatch.
• 12-month warranty included.

Contact us for inquiries: info@oiltechcontrols.com or +86 158 8020 0923.

FAQ

Q: How do I know the EL4034 is the right terminal for my drive?

A: Check the drive command input. If it needs -10 to +10 V, the EL4034 fits well. If it needs 0 to 10 V, a unipolar terminal is cheaper.

Q: Can I use the EL4034 in an ATEX area?

A: Yes, with the right panel design. The Ex marking is II 3 G Ex nA IIC T4 Gc. Follow local rules for Zone 2 use.

Q: Why choose the ES4034 over the EL4034?

A: The ES4034 adds pluggable wiring. That helps when you must swap a terminal fast without redoing every wire.

Q: What causes output error in real panels?

A: Long unshielded cables and ground loops add error. Use shielded twisted pair and keep signal wires away from drives.

Q: How do I check a used EL4034 before buying?

A: Ask for the LED test, channel-by-channel voltage check, and E-bus scan result. A good seller sends these before shipment.
