GE Fanuc IC698CRE030 CPU Module RX3i PACSystem Redundant

IC698CRE030 Redundancy CPU

The IC698CRE030 is a Pentium-M based redundancy CPU from GE Fanuc. It belongs to the RX3i PACSystem series. This CPU provides robust processing for critical control applications. It operates at a rated speed of 600 megahertz. The unit includes 64 MB of user memory for program and data storage. Its built-in Ethernet port supports 10/100 Mbps communication. This port enables web-based monitoring and data transfer. The CPU fits into a VME64 backplane within an RX7i PLC system. It is designed for high-availability systems requiring redundant controllers.

Technical Specifications

Key Features & Compatibility

• Redundancy Ready: Designed for seamless CPU failover in critical processes.
• Integrated Ethernet: Dual RJ-45 ports with auto-negotiation. No external hubs needed.
• Web Monitoring: View PLC status directly from a standard browser.
• Isolated Serial Ports: RS-232 and RS-485 ports for robust field device connectivity.
• Station Manager Port: Dedicated RS-232 port for system management.
• Compatibility: Fully compatible with RX7i PLC systems and VME64 backplanes.
• Diagnostic LEDs: Port activity indicators for quick troubleshooting.

Installation & Debugging

The CPU installs directly into a VME64 backplane. Use a straight-through cable for RS-232 connections. The RS-485 port requires shielded cables to ensure signal integrity. The station manager port also uses a straight-through RS-232 cable. The auto-sensing Ethernet simplifies network integration. No rack switches are necessary for basic operation. The unit supports online debugging and program uploads/downloads. Web-based diagnostics provide real-time system health checks.

Environmental & Certifications

• Temperature Range: 0°C to 60°C (operating)
• Humidity: 5% to 95% (non-condensing)
• EMC Compliance: Meets industrial immunity standards
• Certifications: CE, UL, and RoHS compliant
• Diagnostic Capability: Built-in self-test and error logging
• Interference Immunity: High resistance to electrical noise

Typical Applications

• Critical infrastructure control (water/wastewater)
• Power generation and distribution systems
• Oil and gas pipeline monitoring
• Manufacturing line redundancy
• Data acquisition with high availability

Diagnostic & Maintenance

The Ethernet port supports web-based diagnostics. LED indicators show port and CPU status. The station manager port allows direct configuration. Online monitoring helps identify faults quickly. The CPU logs error events for later analysis. Remote firmware updates are possible via Ethernet. The design simplifies routine maintenance and troubleshooting.

Frequently Asked Questions

Q: Does this CPU support redundant pairs?
A: Yes, it is specifically designed for redundancy applications.

Q: What type of memory does it use?
A: It provides 64 MB of user memory for programs and data.

Q: Can I monitor it remotely?
A: Yes, the built-in Ethernet port enables web-based monitoring.

Q: Is the RS-485 port isolated?
A: Yes, both RS-232 and RS-485 ports are fully isolated.

Q: What cables are needed?
A: Use straight-through cables for RS-232 ports and shielded cables for RS-485.

Why Buy from Oiltech Controls?

Oiltech Controls brings over 15 years of expertise in industrial automation spares. We support global shipments with reliable logistics partners like FedEx, UPS, and DHL. Our inventory includes tested industrial surplus and refurbished options. Every unit undergoes technical verification before shipment. We offer a 12-month warranty on all products. We specialize in supporting obsolete control systems. Contact us for inquiries: info@oiltechcontrols.com or +86 158 8020 0923.

For more details on compatible systems, visit Modicon Quantum Series.
