Product Overview
The GE Fanuc IC697MDL240 is a 16-point isolated discrete input module for the Series 90-70 PLC system. It operates at 120 Volts AC with a 20 ms input filter delay. This module supports reactive inputs and works with 2-wire or 3-wire proximity switches. It features mechanical keying for easy I/O configuration without DIP switches.
Key capabilities: It connects to various AC supply phases. LED indicators show on/off status for each point. The capacitive input design ensures heat dissipation, high reliability, and long life.
Technical Specifications
| Brand | GE Intelligent Platforms / GE Fanuc |
| Series | Series 90-70 |
| Model | IC697MDL240 |
| Type | Discrete Input Module |
| Rated Voltage | 120 VAC |
| Number of Inputs | 16 isolated inputs |
| Input Current (On-state) | 10 mA typical |
| Input Current (Off-state leakage) | 4 mA max |
| Backplane Current Draw | 0.25 A from 5 V bus |
| Frequency | 60 Hz |
| Input Filter Delay | 20 ms |
| LED Indicators | Yes, per point status |
| Power Type | AC only, no DC power |
Environmental & Reliability: The module withstands industrial environments with robust isolation. Its capacitive circuitry offers excellent heat dissipation. Mechanical keying ensures correct replacement.
Installation & Compatibility
- Mounting: Install in any Series 90-70 backplane slot. The mechanical key bolts to the center rail for proper module substitution.
- Wiring: Supports 2-wire or 3-wire proximity switches. Use shielded cables for noisy environments.
- Compatibility: Works with GE Series 90-70 PLC systems. Configure via Windows/MS-DOS programming software over SNP or Ethernet TCP/IP.
- Diagnostics: LED indicators provide real-time point status. The 20 ms filter delay reduces false triggers.
Typical Applications
- Automated assembly lines
- Packaging machinery
- Material handling systems
- Process control panels
- Replacement for legacy Series 90-70 I/O
Certifications & Warranty
- Certifications: UL, CE, and CSA compliant (standard for Series 90-70).
- Warranty: 12-month warranty against defects in material and workmanship.
- Packaging: Each module is shipped in ESD-safe packaging with installation guide.
Frequently Asked Questions
- Q: Can this module replace IC697MDL240 without reconfiguration?
Yes, the mechanical key allows direct replacement. No DIP switch or jumper changes are needed. - Q: What is the maximum cable length?
Keep cable runs under 100 meters for reliable 120 VAC input signals. - Q: Does it support 240 VAC?
No, rated for 120 VAC only. Do not exceed this voltage. - Q: How do I verify input status?
Use the LED indicators or read the input table via programming software.
