Keyence GL-VM08HN Safety Light Curtain – Hand Protection, 8 Beams, Type 4
The GL-VM08HN from Keyence (GL-V series) is a compact, robust metal Type 4 safety light curtain. Moreover, it provides hand protection with 8 beam axes and a 25 mm minimum object size. In addition, this transmitter/receiver set uses optical synchronization and infrared LED (850 nm). Therefore, it is ideal for industrial automation, packaging, and machine guarding. Furthermore, its metal housing ensures long-term durability in harsh factory environments. Consequently, it suits both new installations and retrofit projects. Besides, it needs no separate sync cable. Likewise, its compact 160 mm body fits tight spaces.
Technical Specifications
| Brand | Keyence |
| Model | GL-VM08HN |
| Series | GL-V series |
| Module Type | Safety light curtain (Type 4 ESPE / AOPD) |
| Protection Type | Hand protection |
| Number of Beam Axes | 8 |
| Beam Axis Spacing | 20 mm |
| Detection Height | 140 mm |
| Total Length | 160 mm |
| Minimum Detectable Object | ø25 mm |
| Detecting Distance | 0.3 to 15 m |
| Response Time (OSSD ON→OFF) | Max. 4.1 ms |
| Light Source | Infrared LED (850 nm), Exempt Group (IEC62471) |
| Synchronization | Optical synchronization |
| Effective Angular Aperture | Up to ±2.5° (at 3 m or above) |
| Detection Mode | ON when all beam axes are received |
| Interference Prevention | Up to 2 units by series connection and switch setting |
| Supply Voltage | 24 VDC -20/+25%, ripple (P-P) 10% or less, Class 2 |
| Current Consumption | Transmitter max. 56 mA; Receiver max. 68 mA (OSSD current not included) |
| Control Output (OSSD) | Transistor output x2 (NPN) |
| Maximum Load Current | 150 mA or less |
| Residual Voltage (ON) | Up to 2.5 V (5 m cable) |
| OFF Voltage | Up to 2.0 V (5 m cable) |
| Leakage Current | Up to 0.8 mA |
| Max. Load Capacity | 0.8 µF |
| Load Wiring Resistance | Up to 2.5 Ω |
| Inputs | Short-circuit current approx. 3 mA |
| Communication Ports | None |
| Protocols | None |
| Communication Expansion | None |
| Operating Temperature | -30 to +55 °C (No freezing) |
| Storage Temperature | -30 to +70 °C (No freezing) |
| Relative Humidity | Up to 95 % RH (no condensation) |
| Ambient Light | Incandescent lamp 3,000 lux or less; Sunlight 20,000 lux or less |
| Protection Rating | IP65/IP67 (IEC60529) |
| Overvoltage Category | II |
| Vibration Resistance | 5 to 150 Hz, 1G, 10 cycles each in X/Y/Z |
| Shock Resistance | 15 G, 6 ms pulses, 100 times each in X/Y/Z |
| Material | Main unit Aluminum alloy; upper/lower case PPS (GF40%); front cover Polycarbonate, SUS304 |
| Weight | Transmitter 120 g; Receiver 120 g |
| Dimensions (H×W×D) | Not available |
| Safety Standards | IEC61496-1/-2 (Type 4 ESPE/AOPD), EN ISO13849-1 (Category 4, PL e), IEC61508 (SIL3), UL60947-1 / CSA C22.2 No.60947-1, UL1998 |
| EMC | IEC/EN61496-1, EN55011 Class A, FCC Part15B Class A, ICES-003 Class A |
| Protection Circuit | Supply reverse-connection, per-output short-circuit and surge protection |
| Lifecycle Status | Active (Last verified: 2026-09) |
Installation Guide
- First, mount transmitter and receiver facing each other.
- Then keep alignment within ±2.5° angular aperture.
- Also use optical synchronization – no extra wiring needed.
- Next, connect 24 VDC Class 2 power supply.
- After that, wire OSSD outputs to machine safety circuit.
- In addition, set interference prevention switch for up to 2 units.
- Finally, verify IP65/IP67 seal after installation.
- Meanwhile, check all cable glands for tightness.
- Similarly, confirm all brackets are secure.
- Likewise, test beam alignment with a test rod.
Setup and Maintenance
- First, clean front cover with soft cloth and mild cleaner.
- Then check beam alignment after shock or vibration.
- Also monitor OSSD response time (max. 4.1 ms).
- Moreover, replace unit if leakage current exceeds 0.8 mA.
- In addition, no internal communication ports to configure.
- Finally, use Keyence original cables for best performance.
- Consequently, regular checks extend product lifespan.
- Likewise, keep spare units for critical lines.
- Similarly, log any fault codes for trend analysis.
Compatibility Notes
- First, works with standard 24 VDC control systems.
- Also NPN OSSD outputs – check PLC input type.
- Moreover, series connection allows up to 2 units.
- However, no fieldbus or Ethernet protocol support.
- In addition, compatible with Keyence GL-V series brackets.
- Finally, replace obsolete safety curtains with same beam count.
- Therefore, verify existing wiring before swap.
- Similarly, check mounting hole pattern matches.
- Besides, confirm cable connector pinout is identical.
Certifications
- IEC61496-1/-2 Type 4 ESPE/AOPD
- EN ISO13849-1 Category 4, PL e
- IEC61508 SIL3
- UL60947-1 / CSA C22.2 No.60947-1
- UL1998
- EN55011 Class A, FCC Part15B Class A, ICES-003 Class A
Package List
- Transmitter unit (120 g)
- Receiver unit (120 g)
- Quick installation guide
- Mounting brackets (depending on order)
- No cable included unless specified
Warranty and Shipping
All units come with a 12-month warranty. Moreover, we ship worldwide via FedEx, UPS, and DHL. Therefore, a tracking number is provided after dispatch. In addition, contact us for expedited shipping quotes. Furthermore, all shipments are packed to protect sensitive optical components. Consequently, you receive your order safely and quickly. Besides, we offer tested surplus options for urgent needs. Likewise, we verify every unit before it leaves our warehouse.
Typical Applications
- Hand protection on press machines
- Packaging line guarding
- Robotic cell entry protection
- Automated assembly stations
- Material handling equipment
- Textile and paper machinery
Diagnostic Capabilities
- Indicator LED for power and beam status.
- OSSD output monitors beam interruption.
- Response time under 4.1 ms for fast stop.
- No built-in communication diagnostics.
- External test input available via short-circuit current.
- Interference prevention switch helps multi-unit setups.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipment support to your door.
- Tested industrial surplus and refurbished options.
- 12-month warranty on every unit.
- Technical verification before shipment.
- Support for obsolete control systems.
FAQ
Q: What is the minimum detectable object size?
A: ø25 mm for hand protection.
Q: Can I connect two GL-VM08HN units?
A: Yes, up to 2 units via series connection and switch setting.
Q: What is the response time?
A: Max. 4.1 ms for OSSD channel 0 ON→OFF.
Q: Does it require a separate sync cable?
A: No, it uses optical synchronization.
Q: What is the protection rating?
A: IP65/IP67 (IEC60529).
Q: Is a cable included?
A: No, cable is sold separately unless stated.
Q: What is the warranty period?
A: 12 months from date of shipment.
