Product Description
Keyence GL-VM207FN is a Type 4 safety light curtain set. Moreover, it includes a transmitter and a receiver. The series is GL-V. This model uses a small metal housing. As a result, it protects fingers in industrial machines.
The GL-VM207FN has 207 beam axes. Also, the beam spacing is 10 mm. It detects objects as small as ø14 mm. The detection height is 2060 mm. In addition, the total length is 2080 mm. The detecting distance is 0.3 to 12 m. Response time is max. 12.5 ms. Output is NPN.
This light curtain uses optical synchronization. Therefore, it needs no separate sync wire. The infrared LED is 850 nm. It belongs to Exempt Group under IEC62471. The effective angular aperture is up to ±2.5° at 3 m or above. The detection mode is ON when all beam axes are received. Meanwhile, interference prevention supports up to 2 units by series connection and switch setting.
The GL-VM207FN meets Type 4 ESPE / AOPD requirements. Additionally, it supports Category 4, PL e and SIL3. The housing is robust. The protection rating is IP65/IP67. It works in temperatures from -30 to +55 °C. It resists vibration and shock. Consequently, it is suitable for demanding factory environments.
This model has no built-in communication port. It has no protocol support. It provides 2 transistor outputs as OSSD. The output type is NPN. It includes supply reverse-connection protection. It also includes per-output short-circuit and surge protection.
Technical Specifications
| Brand | Keyence |
| Model | GL-VM207FN |
| Series | GL-V series |
| Module Type | Safety light curtain, transmitter + receiver set |
| Safety Category | Type 4 ESPE / AOPD |
| Protection Type | Finger protection |
| Number of Beam Axes | 207 |
| Beam Axis Spacing | 10 mm |
| Minimum Detectable Object | ø14 mm |
| Detection Height | 2060 mm |
| Total Length | 2080 mm |
| Detecting Distance | 0.3 to 12 m |
| Response Time | Max. 12.5 ms, OSSD channel 0, ON to OFF |
| Light Source | Infrared LED, 850 nm, Exempt Group IEC62471 |
| Synchronization | Optical synchronization |
| Effective Angular Aperture | Up to ±2.5° at 3 m or above |
| Detection Mode | ON when all beam axes are received |
| Interference Prevention | Up to 2 units by series connection and switch setting |
| Supply Voltage | 24 VDC -20/+25%, ripple P-P 10% or less, Class 2 |
| Maximum Load Current | 150 mA or less |
| Residual Voltage ON | Up to 2.5 V at 5 m cable |
| OFF Voltage | Up to 2.0 V at 5 m cable |
| Leakage Current | Up to 0.8 mA |
| Max. Load Capacity | 0.8 µF |
| Load Wiring Resistance | Up to 2.5 Ω |
| Inputs | Short-circuit current approx. 3 mA |
| Control Output | Transistor output x2, NPN |
| Current Consumption | Transmitter max. 191 mA; receiver max. 219 mA, indicator ON, OSSD output current not included |
| Protection Circuit | Supply reverse-connection, per-output short-circuit and surge protection |
| Operating Temperature | -30 to +55 °C, no freezing |
| Storage Temperature | -30 to +70 °C, no freezing |
| Relative Humidity | Up to 95 % RH, no condensation |
| Ambient Light | Incandescent lamp 3,000 lux or less; sunlight 20,000 lux or less |
| Protection Rating | IP65/IP67, IEC60529 |
| Overvoltage Category | II |
| Vibration Resistance | 5 to 150 Hz, 1G, 10 cycles each in X/Y/Z |
| Shock Resistance | 15 G, 6 ms pulses, 100 times each in X/Y/Z |
| Material | Main unit aluminum alloy; upper/lower case PPS GF40%; front cover polycarbonate, SUS304 |
| Weight | Transmitter 1350 g; receiver 1370 g |
| Communication | None |
| Built-in Ports | None |
| Protocols | None |
| Communication Expansion | None |
Installation Guide
- First, mount the transmitter and receiver facing each other.
- Then, keep the beam axes aligned within the effective angular aperture.
- Also, use the 10 mm beam spacing for finger protection layouts.
- In addition, keep the detecting distance between 0.3 m and 12 m.
- Next, connect the 24 VDC supply with correct polarity.
- Moreover, use Class 2 power for stable operation.
- Also, route load wiring with resistance up to 2.5 Ω.
- For series connection, set the switches to prevent interference.
- Finally, check the ON state when all beam axes are received.
- Therefore, protect the front cover from heavy impact.
Commissioning and Maintenance
- First, verify alignment before machine start-up.
- Then, check OSSD output with a suitable tester.
- Also, confirm response time meets machine stop performance.
- Moreover, clean the front cover with a soft cloth.
- In addition, do not use abrasive cleaners on the polycarbonate cover.
- Next, inspect the cable and connector for damage.
- Also, check the IP65/IP67 seal after maintenance.
- Then, test the protective function at regular intervals.
- Furthermore, keep the unit within the operating temperature range.
- Finally, replace damaged units with the same model.
Compatibility Notes
- First, it works as a Type 4 ESPE / AOPD safety device.
- Also, it supports Category 4, PL e applications.
- Moreover, it supports SIL3 safety functions.
- In addition, it uses NPN transistor output for control interface.
- However, it has no built-in communication port.
- Also, it has no protocol support.
- Furthermore, it has no communication expansion option.
- Therefore, it can connect in series with up to 2 units for interference prevention.
- Meanwhile, it uses optical synchronization between transmitter and receiver.
- Consequently, it suits safety circuits that accept NPN OSSD signals.
Certifications
- IEC61496-1/-2: Type 4 ESPE / AOPD
- EN ISO13849-1: Category 4, PL e
- IEC61508: SIL3
- UL60947-1 / CSA C22.2 No.60947-1
- UL1998
- EMC: IEC/EN61496-1, EN55011 Class A, FCC Part15B Class A, ICES-003 Class A
Package List
- 1 x Keyence GL-VM207FN transmitter
- 1 x Keyence GL-VM207FN receiver
- Standard mounting accessories as supplied
- Documentation as supplied
Warranty: 12-month warranty.
Shipping: FedEx, UPS, DHL.
Typical Applications
- First, finger protection on press machines.
- Also, safety guarding on assembly lines.
- Moreover, access protection on automated cells.
- In addition, robotic work cell entry protection.
- Then, packaging machine safety doors.
- Also, material handling equipment guarding.
- Furthermore, metal forming machinery protection.
- Finally, industrial automation safety circuits.
Diagnostic Capability
- First, the indicator shows power and output status.
- Also, detection mode shows ON when all beams are received.
- Moreover, response time supports fast machine stop checks.
- In addition, output short-circuit protection helps reduce downtime.
- Then, surge protection supports stable operation.
- Furthermore, reverse-connection protection helps prevent wiring damage.
- Finally, interference prevention supports reliable multi-unit use.
Why Buy From Oiltech Controls?
- First, more than 15 years in industrial automation spare parts.
- Also, worldwide shipment support.
- Moreover, tested industrial surplus and refurbished options.
- In addition, 12-month warranty.
- Then, technical verification before shipment.
- Furthermore, support for obsolete control systems.
- Also, fast response for urgent maintenance needs.
- Finally, practical support from automation engineers.
Contact us for inquiries: info@oiltechcontrols.com or +86 158 8020 0923.
FAQ
Q: What is the model number?
A: The model is GL-VM207FN.
Q: What brand makes this product?
A: The brand is Keyence.
Q: What series does it belong to?
A: It belongs to the GL-V series.
Q: How many beam axes does it have?
A: It has 207 beam axes.
Q: What is the minimum detectable object size?
A: It detects objects as small as ø14 mm.
Q: What is the detecting distance?
A: The detecting distance is 0.3 to 12 m.
Q: What is the response time?
A: The response time is max. 12.5 ms.
Q: What output type does it use?
A: It uses NPN transistor output x2.
Q: What is the supply voltage?
A: The supply voltage is 24 VDC.
Q: What is the protection rating?
A: The protection rating is IP65/IP67.
Q: What is the operating temperature range?
A: The range is -30 to +55 °C.
Q: Does it have built-in communication?
A: No. It has no built-in communication port.
Q: What safety standards does it meet?
A: It meets IEC61496-1/-2, EN ISO13849-1, IEC61508, UL60947-1, CSA C22.2 No.60947-1, and UL1998.
Q: What is the warranty?
A: The warranty is 12 months.
Q: How is it shipped?
A: We ship by FedEx, UPS, and DHL.
