Keyence IV4-L5M Infrared Ring Light for IV4 Smart Camera
The IV4-L5M is an external infrared ring illumination unit. It is built for the Keyence IV4-500MA smart camera. The IV4-L5M delivers stable IR lighting for inspection tasks. It uses an aluminum die-cast case. The front cover is acrylic. It is ESD safe and meets IEC61340-5-1.
Hardware and Optical Role
- Type: external ring light unit
- Compatible sensor: IV4-500MA
- Illumination source: infrared LED
- Mounts directly to the IV4 camera body
- Supports uniform ring lighting for close-range vision
Electrical and Communication Profile
- Supply voltage: power comes from the connected sensor
- Built-in ports: none
- Protocols: none
- Communication expansion: not supported
- Power consumption and output type: not applicable
Environmental and Physical Data
- Operating temperature: 0 to +50°C, no freezing
- Relative humidity: 85% RH or less, no condensation
- Protection rating: IP67 when attached to a compatible sensor
- IP67 note: not valid with polarizing filters OP-88644, OP-88645, OP-88646, or OP-88647
- Main case material: aluminum die-casting
- Front cover material: acrylic
- Weight: approx. 195 g
Lifecycle and Availability
- Status: active
- Keyence production status: confirmed
- Last verified: 2026-09
- Ideal for legacy IV4 vision systems
- Useful for obsolete line support and replacement
Where the IV4-L5M Fits Best
- IV4-500MA smart camera inspection stations
- Electronics and small-part visual checks
- Low-contrast IR imaging tasks
- ESD-sensitive assembly areas
- Compact machine vision cells with ring light needs
Oiltech Controls’s Insight
The IV4-L5M is not a standalone sensor. It is a dedicated light module. Engineers should pair it only with the IV4-500MA. The IR LED works well where visible light causes glare or reflection. The IP67 rating depends on the attached sensor and filter choice. Confirm your filter setup before use. This unit is a practical choice for maintaining existing IV4 camera lines.
Oiltech Controls Review
- Strong fit for Keyence IV4-500MA users
- Good mechanical protection with die-cast aluminum
- ESD compliance suits electronics manufacturing
- No communication setup needed
- Best for replacement, not for new standalone designs
Shipping and Warranty
- Ships in 24-28 hours
- Carriers: FedEx, UPS, DHL
- Warranty: 12 months
- Technical verification before dispatch
- Global shipment support
Why Buy From Oiltech Controls?
- More than 15 years in industrial automation spare parts
- Worldwide shipping and export handling
- Tested surplus and refurbished options available
- 12-month warranty coverage
- Pre-shipment technical checks
- Support for discontinued and obsolete control systems
FAQ
Q: Can I use the IV4-L5M with any Keyence camera?
No. It is designed for the IV4-500MA. Other cameras may not mount or power it correctly.
Q: Does the IP67 rating always apply?
No. IP67 holds only when the unit is attached to a compatible sensor. It does not hold with certain polarizing filters installed.
Q: Why choose infrared instead of visible light?
IR light reduces glare and improves contrast on some materials. It helps with low-contrast marks and reflective surfaces.
Q: Is this a new or refurbished unit?
We offer tested industrial surplus and refurbished options. Each unit is verified before shipment. Contact us for current stock condition.
Q: How do I confirm compatibility before buying?
Check your camera model first. Confirm it is IV4-500MA. Then review your filter setup. Email us at info@oiltechcontrols.com or message +86 158 8020 0923 for guidance.
