IV4-L4C Ring Light for Keyence IV4 Smart Camera
The IV4-L4C is a white LED ring light from the Keyence IV4 Series. It delivers stable, shadow-reduced illumination for the IV4-400CA smart camera. The unit draws power directly from the sensor. No separate power supply is needed. Its IP67 rating supports harsh factory floors. The aluminum die-cast body and acrylic front cover resist vibration and dust. ESD-safe design meets IEC61340-5-1. This makes the IV4-L4C a practical choice for inline inspection, code reading, and presence detection.
Technical Specifications
| Brand | Keyence |
| Model | IV4-L4C |
| Series | IV4 Series |
| Module Type | External light unit, ring illumination |
| Compatible Sensor | IV4-400CA |
| Illumination | White LED |
| Supply Voltage | Power supplied via connected sensor |
| Power Consumption | Not available |
| Output Type | Not available |
| Built-in Ports | None |
| Protocols | None |
| Communication Expansion | None |
| Operating Temperature | 0 to +50°C, no freezing |
| Relative Humidity | 85% RH or less, no condensation |
| Protection Rating | IP67 when attached to applicable sensor. Excludes polarizing filters OP-88644, OP-88645, OP-88646, OP-88647. |
| Dimensions (H×W×D) | Not available |
| Material | Main case: aluminum die-casting. Front cover: acrylic. ESD safe, IEC61340-5-1 compliant. |
| Weight | Approx. 195 g |
| Lifecycle | Active. Official Keyence production status confirmed. Last verified: 2026-09. |
Installation Guide
- Mount the IV4-L4C onto the IV4-400CA sensor.
- Align the ring light with the camera field of view.
- Secure the unit with the intended mounting hardware.
- Power the light through the connected sensor.
- Confirm IP67 sealing after installation.
- Avoid polarizing filters if IP67 protection is required.
Commissioning and Maintenance
Setup is simple. The sensor powers the ring light. No separate wiring is needed. Clean the acrylic front cover with a soft, lint-free cloth. Check the mounting screws after high-vibration operation. Inspect the seal when the unit is removed or replaced. Keep the lens area free of oil, dust, and coolant mist. Regular inspection helps maintain uniform illumination.
Compatibility Notes
The IV4-L4C works with the Keyence IV4-400CA smart camera. It is part of the IV4 Series external light lineup. It has no built-in ports and no communication protocol. It does not support communication expansion. Use it only with compatible IV4 sensors. Confirm camera model and mounting clearance before ordering.
Certifications and Standards
- ESD safe design
- IEC61340-5-1 compliant
- IP67 rated when attached to an applicable sensor
- IP67 excludes use with OP-88644, OP-88645, OP-88646, OP-88647 polarizing filters
Packing List
- 1 × Keyence IV4-L4C ring light unit
- Protective packaging
- Order documentation
Accessories and mounting hardware are not included unless stated in the quote.
Warranty and Shipping
Oiltech Controls offers a 12-month warranty on this unit. We ship worldwide by FedEx, UPS, and DHL. Each order is packed for safe transport. Tracking details are provided after dispatch. Delivery times depend on destination and customs clearance.
Typical Applications
- Inline visual inspection
- Barcode and label reading
- Presence and position checks
- Small part detection
- Assembly verification
- Factory automation cells
Diagnostic Capability
The ring light has no internal diagnostics, ports, or protocol output. System checks come from the connected IV4-400CA sensor. If illumination drops, inspect the light cover, cable connection, and sensor power. Replace the unit if the LED array fails. This keeps troubleshooting fast and predictable.
Why Buy From Oiltech Controls?
- More than 15 years in industrial automation spare parts
- Global shipment support through FedEx, UPS, and DHL
- Tested industrial surplus and refurbished options
- 12-month warranty for peace of mind
- Technical verification before every shipment
- Support for obsolete and legacy control systems
Questions? Email info@oiltechcontrols.com or message us on WhatsApp at +86 158 8020 0923.
FAQ
Q: What sensor does the IV4-L4C fit?
A: It fits the Keyence IV4-400CA smart camera.
Q: Does the IV4-L4C need a separate power supply?
A: No. The connected sensor supplies power.
Q: What is the protection rating?
A: IP67 when attached to an applicable sensor. Polarizing filters OP-88644, OP-88645, OP-88646, and OP-88647 are excluded.
Q: What is the operating temperature range?
A: 0 to +50°C with no freezing.
Q: What is the warranty period?
A: Oiltech Controls provides a 12-month warranty.
Q: Which couriers do you use?
A: We ship by FedEx, UPS, and DHL.
Q: Is the IV4-L4C still active?
A: Yes. Official Keyence production status is confirmed. Last verified: 2026-09.
