FU-57TZ Keyence Fiber Optic Sensor – Side View, Tough-Flex, 1 m Free-Cut
Product Overview
The Keyence FU-57TZ is a side-view fiber optic sensor unit. It belongs to the FU series from Keyence. This model uses a ø0.5 mm optical axis for small target detection. Its Tough-Flex design allows a minimum bend radius of R2 mm. The fiber length is 1 m and can be freely cut. It works well in tight spaces and moving parts. The sensor is ideal for industrial automation tasks that need high precision and long-term stability.
Technical Specifications
| Brand | Keyence |
| Model | FU-57TZ |
| Series | FU Series (Fiber Optic Sensor Unit) |
| Optical Axis Diameter | ø0.5 mm (0.02″) |
| Beam Emitting Direction | Side |
| Fiber Unit Length | 1 m (39.37″) free-cut |
| Fiber Unit Diameter | ø1.0 mm |
| Minimum Bend Radius | R2 mm (0.079″) Tough-Flex |
| Minimum Detectable Object | ø0.005 mm (0.0002″) |
| Temperature Range | -40 to +50 °C (-40 to 122 °F) |
| Weight | Approx. 5 g |
Measurement Range: Depends on amplifier unit. Works with standard Keyence fiber amplifiers.
Frequency Response: Matches amplifier specs. Typical response up to 50 kHz.
Sensitivity: Detects objects down to 0.005 mm.
Linearity: Stable output across the detection range.
Resolution: High resolution for small part detection.
Temperature Range: -40 to +50 °C.
Environmental Resistance: Tough-Flex fiber resists vibration and bending.
Anti-Interference: Immune to electrical noise. Fiber optic design blocks EMI.
Installation Guide
- Mount the fiber unit near the target area.
- Use the side-view direction for tight spaces.
- Keep bend radius above R2 mm.
- Cut the fiber to needed length with a fiber cutter.
- Connect to a compatible Keyence amplifier.
- Adjust sensitivity on the amplifier.
Setup and Maintenance
- Clean the fiber tip with soft cloth and alcohol.
- Check for bends tighter than R2 mm.
- Verify alignment after machine changes.
- Replace if the fiber jacket is damaged.
- No regular calibration needed for the fiber unit.
Compatibility Notes
The FU-57TZ works with Keyence FS, FU, and other standard fiber amplifiers. It fits most fiber optic sensor systems that use ø1.0 mm fiber. Always confirm amplifier compatibility before use.
Certifications
This product meets CE and RoHS standards. It follows Keyence quality and safety rules. Contact us for detailed certificates.
Package Contents
- 1 x Keyence FU-57TZ fiber unit
- 1 x Protective cap
- 1 x Instruction sheet (basic)
Warranty and Shipping
12-month warranty from Oiltech Controls Limited. We ship via FedEx, UPS, and DHL. Tracking number provided. Fast global delivery.
Typical Applications
- Small part detection on assembly lines.
- Semiconductor wafer mapping.
- Electronic component presence checks.
- Medical device manufacturing.
- Robotic gripper feedback.
Diagnostic Capabilities
The sensor helps find misalignment, broken fibers, and contamination. Use the amplifier’s LED indicator for quick status. The Tough-Flex design reduces false alarms from vibration. Fast response time aids high-speed diagnostics.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipment support with FedEx, UPS, DHL.
- Tested industrial surplus and refurbished options.
- 12-month warranty on every unit.
- Technical verification before shipment.
- Support for obsolete control systems.
Contact us for inquiries: info@oiltechcontrols.com or +86 158 8020 0923 (WhatsApp).
FAQ
Q: What is the minimum detectable object?
A: ø0.005 mm with a suitable amplifier.
Q: Can I cut the fiber?
A: Yes. It is free-cut. Use a proper fiber cutter.
Q: What is the bend radius?
A: R2 mm minimum for Tough-Flex.
Q: What is the warranty?
A: 12 months from Oiltech Controls Limited.
Q: Which couriers do you use?
A: FedEx, UPS, DHL.
