IV-G150MA Keyence IV-G Series Sensor Head – Narrow View, Monochrome, Auto Focus
Discontinued model. Recommended replacement available. Last verified: 2026-09.
Product Overview
The Keyence IV-G150MA is a compact sensor head from the IV-G Series. It pairs with the IV-G10 amplifier for machine vision tasks.
This is a narrow field-of-view monochrome model with automatic focus. It captures clear images at short to medium distances.
Built for industrial inspection, it offers IP67 protection, white LED pulse lighting, and a 1/3-inch CMOS sensor. The head is lightweight at only 75 g.
Technical Specifications
| Brand | Keyence |
| Model | IV-G150MA |
| Series | IV-G Series |
| Module Type | Sensor head (narrow view, monochrome) |
| Installed Distance | 40 to 150 mm |
| Field of View | 40 mm: 8 × 6 mm; 150 mm: 32 × 24 mm |
| Image Sensor | 1/3-inch monochrome CMOS, 752 × 480 px |
| Focus Adjustment | Auto focus |
| Illumination | White LED, pulse or DC switchable |
| Resolution | 752 × 480 pixels (approx. 0.36 MP) |
| Temperature Range | 0 to +50°C (no freezing) |
| Humidity | 35 to 85% RH (no condensation) |
| Protection Rating | IP67 |
| Supply Voltage | Via connected amplifier |
| Communication | None built-in; expands via amplifier |
| Weight | Approx. 75 g |
| Dimensions (H×W×D) | Not available |
| Certifications | CE, RoHS (typical for series; verify per unit) |
Core Performance Highlights
- Measurement range: 40–150 mm working distance
- Resolution: 752 × 480 px monochrome CMOS
- Focus: Auto focus saves setup time
- Lighting: White LED, pulse or DC mode
- Environment: IP67, 0–50°C, 35–85% RH
- Noise immunity: Stable with amplifier grounding and shielded cable
- Linearity: Maintained across field of view via auto focus
- Frequency response: Depends on amplifier settings (pulse/DC)
Installation Guide
- Mount the IV-G150MA at 40–150 mm from the target.
- Connect to IV-G10 amplifier with the dedicated cable.
- Keep the lens clean. Use the auto focus to lock sharpness.
- For IP67, ensure the cable connector is fully seated.
- Avoid direct sunlight and strong EMI sources.
Setup and Maintenance Convenience
Auto focus reduces manual adjustment. The head is small and light. You can swap it quickly.
No internal ports mean fewer failure points. All setup goes through the amplifier. This keeps the head sealed and rugged.
Compatibility Notes
- Works only with Keyence IV-G10 amplifier.
- Uses a dedicated cable (not standard USB or Ethernet).
- Communication and output are handled by the amplifier.
- Check amplifier firmware for full feature support.
Certifications, Packaging and Warranty
- Certifications: CE, RoHS (typical; confirm with unit label)
- Packaging: 1 × IV-G150MA sensor head, 1 × quick guide (cable sold separately)
- Warranty: 12 months from Oiltech Controls
- Shipping: FedEx, UPS, DHL (worldwide)
Typical Applications and Diagnostics
- Presence/absence checks on small parts
- Position verification in assembly cells
- Orientation detection for connectors and pins
- Diagnostics: Amplifier shows live image and focus status. Use it to check alignment and lighting.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts
- Worldwide shipping support
- Tested surplus and refurbished options
- 12-month warranty on every unit
- Technical check before dispatch
- Help with obsolete control systems
FAQ
Q: Is the IV-G150MA discontinued?
A: Yes. Keyence marks it discontinued. We offer tested replacements.
Q: What amplifier does it need?
A: It works only with the IV-G10 amplifier.
Q: Does it come with a cable?
A: Cable is not included. Use the dedicated Keyence cable.
Q: What is the warranty?
A: 12 months from Oiltech Controls.
Q: How fast is shipping?
A: We ship via FedEx, UPS, or DHL. Lead time varies by stock.
