Product Overview
MPX22A-DFC20A-MPI-0125-5E3-CA-C is a decentralized field-mounted inverter from SEW-EURODRIVE, part of the MOVIPRO® technology series. This Size 2E unit delivers 12.5 A and 5.5 kW with PROFINET IO direct fieldbus communication. The CA variant comes without the MOVILINK DDI motor interface and uses standard motor connections. Built for IP65 environments, it supports U/f, VFCplus, CFC, and ELSM control modes. It works with SEW synchronous and asynchronous motors as well as third-party motors. Encoder evaluation covers sin/cos, TTL/HTL, RS422, and HIPERFACE. The unit includes 12 digital inputs, 8 digital outputs, 1 relay, 2 analog inputs, and 2 analog outputs. Brake control options include DC 24 V (BMV5), AC 230-460 V (BD1B), and safe brake (SBM). Fanless design applies up to 24 A. This C generation inverter suits demanding industrial automation tasks.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | SEW-EURODRIVE |
| Model | MPX22A-DFC20A-MPI-0125-5E3-CA-C |
| Series | MOVIPRO® technology Decentralized Inverter |
| Supply Voltage | 3 x AC 380-500 V, 50-60 Hz ±10% |
| Nominal Line Current (400 V) | 11.3 A |
| Nominal Line Current (480 V) | 9.42 A |
| Rated Output Current | 12.5 A |
| Rated Power (Async Motor) | 5.5 kW |
| Apparent Output Power | 8.7 kVA |
| Overload Capacity | 200% I_N for 3 s at 4 kHz; 100% I_N continuous at 4 kHz |
| DC Link Voltage | DC 560 V |
| PWM Frequency | 4 / 8 / 16 kHz adjustable |
| Max Output Frequency | U/f: 599 Hz; VFCplus: 250 Hz; CFC: 500 Hz; ELSM: 500 Hz |
| Protection Rating | IP65 (EN 60529) |
| Operating Temperature | -25 to +40 °C (no derating); +40 to +60 °C (derating) |
| Storage Temperature | -25 to +70 °C (non-condensing) |
| Relative Humidity | Non-condensing |
| Dimensions (H×W×D) | 300 × 480 × 162 mm (without interface box); 364 × 620 × 180 mm (with interface box) |
| Weight | Approx. 18.0 kg |
| Communication | PROFINET IO via M12 4-pin D-coded connectors (DFC20A) |
| Safety Options | PROFIsafe, CIP Safety, Safety over EtherCAT via MOVISAFE; CSB31A, CSS.1A, CSA31A |
Installation Guide
- Mount the inverter vertically on a flat, vibration-free surface. Use the IP65 rated enclosure for field installation.
- Connect the 3-phase supply (380-500 V AC) to the line terminals. Observe the C2 EMC filter integrated in the 5E3 variant.
- Use M12 4-pin D-coded connectors for PROFINET IO. The direct fieldbus port simplifies wiring.
- For brake control, select BMV5 (DC 24 V), BD1B (AC 230-460 V), or SBM safe brake option.
- Ensure the ambient temperature stays within -25 to +40 °C for full load. Derate above 40 °C up to 60 °C.
- Keep the fanless design in mind: allow free air circulation around the heat sink. Do not block ventilation paths.
Commissioning and Maintenance
- Configure control mode via parameter set: U/f, VFCplus, CFC, or ELSM. Each mode suits different motor and dynamic requirements.
- Encoder evaluation supports sin/cos, TTL/HTL, RS422, and HIPERFACE. Connect the encoder to the respective interface.
- Use the PROFINET IO diagnostic functions for quick fault tracing. The unit reports status over the fieldbus.
- Maintenance is minimal: check connections, clean the heat sink, and verify firmware. The fanless design reduces wear.
- For safety functions, add the MOVISAFE option (CSB31A, CSS.1A, CSA31A) when required.
Compatibility Notes
- Works with SEW synchronous and asynchronous motors plus third-party motors.
- The CA variant has no MOVILINK DDI motor plug. Standard motor connection is used instead.
- DFC20A provides PROFINET IO. Other DFC variants offer EtherCAT/SBusPLUS (DFC1) and EtherNet/IP + Modbus TCP (DFC3).
- Integrates into the MOVI-C® automation system and supports common industrial networks.
- Safety expansion: PROFIsafe, CIP Safety, and Safety over EtherCAT via MOVISAFE.
Why Buy From Oiltech Controls?
- 15+ years of industrial automation spare parts experience
- Global shipment support with FedEx, UPS, DHL
- Tested industrial surplus and refurbished options
- 12-month warranty on all products
- Technical verification before shipment to ensure function
- Support for obsolete control systems
Typical Applications
- Decentralized conveyor systems in automotive and logistics
- Material handling with field-mounted inverters
- Packaging machines requiring precise speed control
- Food and beverage lines with IP65 washdown areas
- Retrofit projects for legacy SEW drive systems
Diagnostics Capabilities
- PROFINET IO diagnostics provide real-time fault codes and status
- Integrated overload monitoring: 200% for 3 s at 4 kHz
- Encoder signal monitoring for sin/cos, TTL/HTL, RS422, HIPERFACE
- Safe brake (SBM) feedback ensures brake integrity
- Communication watchdog and error counters accessible via fieldbus
FAQ
- Q: What is the difference between CA variant and standard?
A: The CA variant has no MOVILINK DDI motor interface. It uses standard motor connection instead. - Q: Can I use this inverter with third-party motors?
A: Yes, it supports SEW motors and third-party motors with encoder feedback. - Q: What is the warranty period?
A: 12 months from the date of purchase. - Q: How fast is shipping?
A: We ship via FedEx, UPS, or DHL. Delivery time depends on destination. - Q: Is technical support available?
A: Yes, contact us at info@oiltechcontrols.com or +86 158 8020 0923.
Packaging and Warranty
- 1 × MPX22A-DFC20A-MPI-0125-5E3-CA-C inverter
- 1 × quick start guide
- 1 × safety information sheet
- 12-month warranty covering manufacturing defects
- Shipping via FedEx, UPS, or DHL with tracking
