Product Overview
The Schneider Electric BMXP3420102 is a robust processor module for the Modicon M340 automation platform. It provides high-speed control for complex industrial applications. This module manages large-scale I/O and integrates easily into existing control architectures. Engineers rely on this unit for its rapid performance and clear diagnostic feedback.
Technical Specifications
| Attribute | Detail |
|---|---|
| Brand / Model | Schneider Electric / BMXP3420102 |
| Discrete I/O | Max 1024 (Multi-rack) |
| Analog I/O | Max 256 (Multi-rack) |
| Internal RAM | 4096 kB Total |
| Execution Time | 0.12 µs for Boolean logic |
| Operating Temp | 32 to 140 °F (0 to 60 °C) |
Core Performance and Features
- Fast Processing: Operates at 6.4 Kinst/ms for efficient logic execution.
- Network Options: Supports Modbus and CANopen for flexible communication.
- Easy Diagnostics: Onboard LEDs and counters simplify system status monitoring.
- Flexible Scale: Compatible with configurations up to 11 slots and 4 racks.
- Robust Protection: Rated IP20 for reliable operation in industrial settings.
Installation and Maintenance
The BMXP3420102 installs quickly into Modicon M340 racks. Secure the module, connect your cables, and use the USB port for fast programming. The unit features built-in diagnostics for reduced maintenance time.
Certifications and Warranty
- Global Standards: CE, UL, CSA, RCM, EAC, and Merchant Navy.
- Warranty: Guaranteed for 12 months from the date of purchase.
Typical Applications
Use this processor in assembly lines, water treatment, HVAC systems, and motion control setups.
FAQ & Contact
Q: Does this model include Ethernet?
A: No, it focuses on Modbus and CANopen. Contact us for Ethernet versions.
Q: How do you ship?
A: We ship via Fedex, UPS, and DHL.
