2200-01702 TR Electronic Laser Distance Sensor

Overview

The 2200-01702 stands as a premier optical solution for extended linear measurement tasks in automated facilities. Engineered by TR Electronic, this Class 2 laser sensor eliminates mechanical wear while maintaining 1.0mm resolution across a 170-meter range. Its Ethernet/IP compatibility and radial M12 connectivity make the 2200-01702 a robust choice for heavy-duty system integration. For availability, contact info@oiltechcontrols.com or message +86 158 8020 0923.

Technical Performance Profile

• Brand: TR Electronic
• Model Designation: 2200-01702
• Effective Range: 170 Meters (Full Stroke Linearized)
• Communication Protocol: Ethernet/IP
• Signal Accuracy: 1.0 mm Resolution
• Voltage Requirement: 18 to 27 VDC
• Physical Interface: RS485 Output Level
• Protection Rating: IP65 Dust and Water Resistance
• Optical Safety: Laser Protection Class 2
• Connector Geometry: Radial Positioning (M12 Type)
• Programming: Fully Programmable Logic

Oiltech Controls Review

• The 2200-01702 is particularly impressive for its signal stability over the 170m span compared to standard 125m models.
• Engineering teams value the Ethernet/IP integration which allows for remote parameterization without physical access to the sensor.
• In our experience, the 2200-01702 excels in environments where mechanical encoders fail due to vibration or cable stretch.
• The linearized output ensures that the distance data is PLC-ready with minimal scaling required in the software.
• We recommend the 2200-01702 for high-speed logistics where millisecond response times are mandatory.

Equipment Application Range

• Long-Span Gantry Cranes: Precise positioning for shipyard and steel mill cranes.
• High-Speed Shuttles: Navigation for ASRS systems in large distribution centers.
• Rail-Bound Vehicles: Distance tracking for industrial transfer cars and trolleys.
• Stage Technology: Accurate height and position control for theater lift systems.
• Automated Parking Systems: Multi-level car lift alignment and platform tracking.

Logistics & Service Excellence

• Shipping Speed: Dispatch within 24-28 hours from stock.
• Carrier Options: Global delivery via DHL, UPS, or Fedex.
• Warranty Terms: 12-Month Quality Guarantee for all industrial users.
• Support Availability: Technical consultation available via info@oiltechcontrols.com.

Engineering FAQ & Selection Guide

• Q: How does the 2200-01702 handle 170m without signal drop?

  A: It utilizes a high-gain receiver circuit and requires the use of specialized Reflective-Foil to maintain signal integrity at peak distances.

• Q: Can I replace a standard 125m sensor with this 170m 2200-01702 model?

  A: Yes, as long as the mounting footprint (Drawing 04-K2200-014) and interface match, the 2200-01702 offers backward compatibility with extra range.

• Q: What is the most common cause of measurement errors?

  A: Misalignment of the laser beam on the reflector over long distances; we recommend using a precision mounting bracket for fine-tuning.

• Q: Is the 2200-01702 suitable for outdoor use?

  A: While IP65 rated, we recommend a protective sun/rain cover if the sensor is exposed to direct heavy weather or extreme sunlight.

• Q: Does the Ethernet/IP interface support DLR (Device Level Ring)?

  A: Please refer to the specific TR-ELE-TI-DGB-0014 pinout; generally, these units are configured as standard Ethernet/IP nodes.
