A02B-0281-C071 FANUC 10.4 Inch LCD Display Monitor | 800 x 600 Color Panel Mount Unit
The A02B-0281-C071 is a FANUC 10.4 inch color LCD monitor for industrial CNC panels. It runs at 800 x 600 pixels and supports graphic and soft key display. It mounts on a panel and accepts 100-240 VAC. The unit suits legacy FANUC control cabinets. It replaces dim or failed displays in aging machines. Oiltech Controls tests each unit before shipment.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts
- Worldwide shipping by FedEx, UPS, and DHL
- Tested surplus and refurbished options
- 12-month warranty on eligible parts
- Technical check before every shipment
- Support for obsolete control systems
Technical Data
- Brand: FANUC
- Model: A02B-0281-C071
- Series: A02B
- Product Type: Display Monitor
- Display Size: 10.4 inch LCD
- Resolution: 800 x 600 pixels
- Display Type: Color LCD with graphic and soft keys
- Brightness: 300 cd/m²
- Response Time: 8 ms
- Input Voltage: 100-240 VAC
- Mounting Type: Panel Mount
- Operating Temperature: 0°C to 55°C
- Weight: 6.25 lbs (2.83 kg)
Compatible Equipment
- FANUC CNC control panels
- FANUC 0i, 16i, 18i, and 21i series cabinets
- Legacy machining centers and lathes
- Industrial operator stations
- Automation cells with panel mount displays
- Obsolete FANUC monitor replacement projects
Oiltech Controls Review
- The A02B-0281-C071 is a direct fit for many aging FANUC panels.
- 800 x 600 resolution gives clear text and graphics for CNC operation.
- 8 ms response time supports fast screen updates.
- 300 cd/m² brightness works in normal factory lighting.
- 100-240 VAC input reduces power configuration issues.
- Panel mount design keeps installation simple.
Oiltech Controls’s Insight
- Check your existing monitor label before ordering.
- Confirm connector type and pinout on the control side.
- Inspect panel cutout size before installation.
- Replace aged backlights if brightness drops over time.
- Keep cabinets cool to extend LCD life.
- Ask us for cross-reference help on hard-to-find displays.
Installation Notes
- Power down the control cabinet before removal.
- Label all cables before disconnecting the old monitor.
- Use the original mounting brackets when possible.
- Check ground and shield connections after install.
- Verify display and soft key response after power-up.
- Test brightness and contrast in the actual panel.
Warranty and Shipping
- 12-month warranty on eligible parts
- 24-28 hour dispatch after order confirmation
- Shipping by FedEx, UPS, and DHL
- Tracking number sent after shipment
- Export packing for safe transport
- Contact info@oiltechcontrols.com or +86 158 8020 0923
FAQ
Q: Will the A02B-0281-C071 fit my FANUC CNC panel?
A: It fits many FANUC control cabinets that use a 10.4 inch panel mount display. Check your old monitor label and connector first. Send us photos and we can help confirm fit.
Q: What should I check before buying a replacement display?
A: Confirm screen size, resolution, input voltage, and connector type. Also check the panel cutout and mounting holes. These details prevent wrong orders and downtime.
Q: Why does brightness matter in a factory display?
A: Lower brightness makes text hard to read under shop lights. This unit runs at 300 cd/m². That level supports normal CNC operation and reduces eye strain.
Q: How do I know if my current monitor is failing?
A: Common signs include dim screen, flicker, lines, slow response, or dead soft keys. Backlight aging is common in old LCD panels. Replace the unit before it stops production.
Q: Does Oiltech Controls test the monitor before shipping?
A: Yes. We verify power-up, display output, and key response when possible. We also check for visible damage and connector condition. Tested stock lowers installation risk.
