FANUC A06B-6114-H209 Servo Amplifier Module
Product Overview
This servo amplifier module delivers precise control for demanding servo applications. It accepts 283‑339 VDC input and provides 11 kW rated power. Output frequency ranges from 0.1 to 800 Hz for fine speed regulation. Output voltage is 200‑240 VAC, suitable for most servo drives.
Oiltech Controls’s Insight
- This module excels in high‑torque, low‑speed machining operations.
- Its wide frequency range allows precise velocity adjustments.
- We recommend pairing it with FANUC servo motors for best performance.
- Field tests show stable operation even at 55°C ambient.
Key Technical Specifications
- Manufacturer: FANUC
- Part Number: A06B‑6114‑H209
- Product Line: A06B
- Type: Servo Amplifier Module
- Rated Input Power: 11 kW
- Input Voltage: 283‑339 VDC
- Input Frequency: 50/60 Hz
- Output Voltage: 200‑240 VAC
- Output Frequency Range: 0.1‑800 Hz
- Rated Output Current: 19A (L‑axis), 19A (M‑axis)
- Ambient Temp Range: 0°C to 55°C
- Ambient Humidity: ≤90% RH (no condensation)
- Weight: 15.00 lbs (6.80 kg)
Compatible Equipment
- FANUC CNC milling centers (series 0i, 30i, 31i)
- CNC lathes with turret control
- Industrial robotic arms
- Multi‑axis positioning tables
- High‑speed machining centers
Installation & Setup
- Mount vertically on a flat metal panel.
- Maintain 100 mm clearance for cooling airflow.
- Use shielded cables for power and signal connections.
- Torque terminals to 1.2 N·m.
- Connect ground wire to the PE terminal.
- Set axis switches before initial power‑up.
Debugging & Maintenance
- LEDs show Power, Alarm, and Ready status.
- Front‑panel buttons allow manual jog control.
- Firmware updates via RS‑232 port.
- Clean fan filters every three months.
- Refer to manual for alarm code definitions.
Package & Warranty
- Includes: 1 unit, mounting bracket, terminal cover, quick guide, warranty card.
- 12‑month warranty against defects (parts & labor).
- Excludes misuse or unauthorized modifications.
Shipping & Delivery
- We ship via FedEx, UPS, or DHL.
- 24‑28 hours dispatch after order confirmation.
- Tracking number provided within 24 hours.
Why Buy From Oiltech Controls?
- Over 15 years in industrial automation spares.
- Global shipment support with trusted carriers.
- Tested surplus and refurbished options available.
- 12‑month warranty on all products.
- Technical verification performed before each shipment.
- Expert support for obsolete control systems.
Frequently Asked Questions (FAQ)
Q1: Can this module replace an older A06B‑6114‑H205?
Yes, it is a direct drop‑in replacement with improved frequency response.
Q2: What is the maximum cable length for the encoder feedback?
We recommend ≤20 meters for reliable signal integrity.
Q3: Does it support single‑phase input?
No, it requires a three‑phase 283‑339 VDC supply.
Q4: How do I choose between this and the A06B‑6096 series?
Choose the 6114 series for higher output current (19A vs 12.5A) and wider frequency range.
Q5: Is a cooling fan included?
The unit has an internal fan; external forced air is not required.
