EDS-2016-ML-SS-SC | MOXA | Industrial Unmanaged Ethernet Switch
The EDS-2016-ML-SS-SC delivers stable Ethernet connectivity for industrial automation systems with mixed copper and fiber interfaces.
This model supports high port density, redundant power input, and reliable communication under demanding environmental conditions.
Series Engineering Overview – EDS-2016-ML
- The EDS-2016-ML series targets industrial edge networking with deterministic data forwarding and minimal latency.
- The architecture integrates copper and fiber ports to support hybrid network topologies in automation systems.
- Engineers rely on DIP switch configuration for QoS, storm protection, and port alarm without software tools.
- The design ensures stable operation in electrically noisy environments using enhanced EMC protection standards.
Port Configuration and Network Performance
- 14 × 10/100BaseT(X) RJ45 ports support auto-negotiation and auto MDI/MDI-X functionality.
- 2 × 100BaseFX single-mode SC ports enable long-distance fiber communication.
- IEEE 802.1p QoS prioritizes critical traffic in real-time control applications.
- 8K MAC table capacity improves device handling in complex industrial networks.
- 2 Mbit packet buffer stabilizes traffic during peak communication loads.
Power Design and Protection Mechanism
- Dual redundant power inputs improve system availability in critical operations.
- Wide voltage input range supports 12/24/48 VDC industrial power systems.
- Operating voltage extends from 9.6 to 60 VDC for flexible deployment.
- Reverse polarity and overload protection prevent damage from wiring errors.
- Terminal block connection simplifies field wiring and maintenance tasks.
Mechanical Structure and Installation
- Compact metal housing ensures durability and efficient heat dissipation.
- IP30 protection rating suits installation inside industrial control cabinets.
- Supports DIN-rail mounting for quick installation in automation panels.
- Optional wall mounting kit allows flexible installation scenarios.
- Dimensions remain compact to optimize cabinet space utilization.
Environmental and Compliance Capability
- Operating temperature range covers -10°C to 60°C industrial environments.
- High EMC immunity meets IEC 61000 standards for interference resistance.
- Certified for hazardous locations including Class I Division 2 and ATEX environments.
- Railway, marine, and traffic certifications support multi-industry applications.
- MTBF reaches 2,070,826 hours, ensuring long-term operational reliability.
Typical Applications and Device Compatibility
- Connects PLC systems, remote I/O modules, and industrial controllers in automation lines.
- Supports SCADA communication networks in oil, gas, and energy sectors.
- Integrates with industrial cameras and sensors requiring stable Ethernet transmission.
- Works with transportation control systems and railway signaling networks.
- Suitable for marine automation systems with certified environmental resilience.
Oiltech Controls’s Insight
- The EDS-2016-ML-SS-SC balances port density and fiber capability for hybrid industrial networks.
- Dual power redundancy significantly improves uptime in mission-critical systems.
- DIP switch control offers practical advantages in environments without engineering laptops.
- This model suits engineers who prioritize stability over advanced managed switching features.
Logistics and Service Commitment
- We provide a 12-month warranty covering standard industrial usage conditions.
- Orders ship within 24–28 hours after confirmation and payment processing.
- Global delivery uses FedEx,
UPS, and
DHL. - Each unit undergoes inspection before shipment to ensure functional integrity.
FAQ – Engineering Selection Guide
- How do I select between single-mode and multi-mode fiber ports?
Choose single-mode fiber for long-distance communication above several kilometers in industrial networks. - When should I use QoS in this switch?
Enable QoS when handling time-sensitive traffic such as PLC control signals or real-time monitoring data. - Is redundant power necessary for my application?
Use redundant inputs in systems where downtime leads to production loss or safety risks. - What installation environment suits this model best?
Install inside control cabinets with proper ventilation and stable industrial power supply conditions. - How can I improve long-term network stability?
Use industrial-grade cables, maintain grounding, and avoid exceeding MAC table capacity during expansion.
