Schneider Triconex 3451 SRO Module | 32-Channel Relay

3451 Triconex SRO Module: High-Density Relay Interface

The 3451 Solid-State Relay Output (SRO) module serves as a versatile interface for non-critical points within the Triconex safety environment. While the module itself is non-triplicated, it receives triple-channel signals from the Main Processors (MPs) and performs internal voting to drive its 32 independent relays. This architecture makes the 3451 an ideal choice for driving annunciator panels and external signal hardware that require isolated switching logic. For immediate stock availability or technical deployment, reach out to info@oiltechcontrols.com or contact us via WhatsApp at +86 158 8020 0923.

Core Technical Parameters

• Manufacturer: Invensys / Triconex
• Model Number: 3451
• Output Points: 32 Channels (Commoned in pairs)
• Nominal Voltage: ±24 VDC
• Switching Capacity: 15 W resistive maximum power per channel
• Current Handling: 0.5 A nominal; 0.7 A over-current maximum
• Isolation: 500 VDC (Earth to Protective Earth) and 800 VDC (Logic)
• Off-State Leakage: Ultra-low current leakage at <100 PA to prevent false triggers.
• Protection: Utilizes 0.75 A fast-acting fuses mounted on the compatible 2451 baseplate.

Oiltech Controls’s Insight & Application Compatibility

• The 3451 provides an essential bridge for “non-triplicated” loads that still require the high-level diagnostic oversight of a Tricon system.
• We recommend using this module specifically for status lamps, audible alarms, or high-impedance interfacing.
• The loop-back circuit allows the module to verify relay state changes even if no load is currently connected.
• Compatible with the Model 2451 SRO Baseplate and suitable for control room light boxes and remote sirens.
• Engineers should leverage the hot-spare support to maintain non-critical alerts during maintenance cycles.

Diagnostic & Operational Features

• Triple Voting Logic: Receives three sets of data from MPs to ensure output command integrity before relay execution.
• Fault Identification: The dedicated Fault indicator alerts operators to specific channel issues without implying a total module failure.
• Continuity of Service: Guaranteed to maintain proper operation even in the presence of a single hardware fault.
• Hot-Spare Support: Ready for redundant configuration to allow seamless replacement of a faulty unit.
• Mechanical Security: Physical keying prevents improper installation into non-SRO baseplates.

Logistics & Service Commitment

• Standard Warranty: Full 12-month quality guarantee provided on all units.
• Shipping Speed: Rapid dispatch within 24-28 hours from order confirmation.
• Express Carriers: Global delivery via FedEx, UPS, and DHL.
• Package Profile: Ships at approximately 2.0 kg with reinforced industrial-grade protection.

Professional FAQ & Selection Guide

• Is the 3451 module suitable for high-demand safety trip functions?
  No, this module is categorized for non-critical points; for safety-critical trips, you should use TMR triplicated digital output modules.
• What happens if a fuse blows on the baseplate?
  The 3451 loop-back circuit will detect the discrepancy in the relay state, and system diagnostics will flag the fault for the specific channel.
• How does the SRO handle multiple faults?
  While guaranteed for a single fault, the robust design often allows continued operation across multiple faults depending on their location.
• Selection Guide: Can I install this into a standard digital input baseplate?
  No, the 3451 is mechanically keyed specifically for the Model 2451 SRO baseplate to prevent hardware damage.
• Experience Tip: Why is the off-state leakage so low on this model?
  The <100 PA leakage ensures that sensitive high-impedance annunciator inputs do not “ghost trigger” when the relay is OFF.
