3482 Triconex Analog Output Module High-Current TMR

Overview

The 3501T is a high-integrity Triconex Digital Input Module designed for Triple Modular Redundant (TMR) safety architectures. Operating at 115 VAC/VDC, this 3501T module features 32 non-commoned, opto-isolated points that provide galvanic separation between field sensing and logic processing. With 100% triplication of signal paths, the unit ensures maximum availability and failsafe operation for critical industrial processes.

Oiltech Controls’s Insight

• The 3501T excels in electrical noise rejection due to its 32 VAC/VDC hysteresis.
• Independent microprocessors per channel facilitate high-speed voting at the main processor level.
• Fault indicators distinguish between channel anomalies and total module failures to prevent nuisance trips.
• The module is guaranteed to operate properly even in the presence of a single channel fault.
• Contact us at info@oiltechcontrols.com or via WhatsApp: +86 158 8020 0923 for priority stock.

Core Technical Parameters

• Module Type: 3501T TMR Digital Input (DI)
• Input Points: 32 points, fully isolated, non-commoned
• Voltage Range: Dual-rated for 90-155 VAC or 90-155 VDC
• Switching Thresholds: OFF to ON > 86V; ON to OFF < 28V
• Input Delay: Faster than 8ms (OFF to ON) and 15ms (ON to OFF)
• Isolation Rating: 1500 VDC point-to-point; 2500 VDC to chassis
• Frequency Response: Compatible with DC or 47-63 Hz AC signals
• Input Impedance: Nominal Field Power Load of 1.5 Watts per ON point
• Diagnostics: PASS, FAULT, and ACTIVE status indicators per channel

System Compatibility & Equipment

• Safety Systems: Tricon V9, V10, and V11 Safety Instrument Systems (SIS).
• Field Devices: Limit switches, motor starter auxiliary contacts, and flame detectors.
• Termination Panels: Compatible with 9561-110 (Non-Commoned) and 9561-810 (Commoned).
• External Cabling: Utilizes 9101-010 fanned-out cables for rack-to-panel connection.
• Loopback Testing: Supports 9141-010 ERT LoopBack Cables for enhanced diagnostic testing.

Logistics and Warranty Terms

• Warranty: 12-month technical warranty included for all 3501T units.
• Worldwide Shipping: Global express delivery via FedEx, UPS, and DHL.
• Dispatch: Guaranteed shipment within 24 to 48 hours of order confirmation.
• Color Code: Red faceplate identification for standard high-voltage DI modules.

Buying Guide & FAQ

How does the 3501T handle a single channel fault?

• The module uses 2-out-of-3 voting; a single fault activates the Fault LED but does not stop module operation.

What is the difference between commoned and non-commoned panels?

• Non-commoned panels (9561-110) maintain total isolation for each point, whereas commoned panels share return lines.

Can the 3501T be used for 125VDC battery monitoring?

• Yes, its 90-155 VDC range makes it ideal for utility-grade 125VDC digital feedback signals.

Is a stuck-test diagnostic available for the 3501T?

• No, the 3501T relies on triplicated channel comparisons for fault detection rather than active pulsing.

How do I confirm the module is active in the Tricon chassis?

• The “ACTIVE” LED will be illuminated, indicating the module is currently processing field data. Reach us at +86 158 8020 0923 for setup help.
