A02B-0047-C800 FANUC Terminator Kit 20-Pin HONDA Connector

A02B-0047-C800 FANUC Terminator Kit

The A02B-0047-C800 is a FANUC terminator kit with a 20-pin male HONDA connector. It belongs to the A02B series. This kit works from -40 to 105°C in non-condensing conditions. Insulation resistance is 1,000 megaohms or more at 500 VDC. Contact resistance stays at 5 milliohms or less. Withstand voltage reaches 1,000 VAC for 1 minute. Humidity tolerance covers 90% to 95% RH. The square connector uses receptacles or crimp pins. It weighs only 0.06 kg. Therefore, it suits tight industrial panels and legacy FANUC systems.

Technical Specifications

• Brand: FANUC
• Model: A02B-0047-C800
• Series: A02B
• Product Type: Terminator Kit with HONDA Connector
• Connector Type: 20-pin male connector
• Connector Shape: Square
• Connection Direction: Straight
• Termination Style: Receptacles or crimp pins
• Ambient Operating Temp.: -40 to 105°C, non-condensing
• Insulation Resistance: 1,000 megaohms or more at 500 VDC
• Contact Resistance: 5 milliohms or less
• Humidity Tolerance: 90% to 95% RH, non-condensing
• Withstand Voltage: 1,000 VAC for 1 minute
• Weight: 0.06 kg / 0.13 lbs

Performance Profile

• Measurement Range: Voltage withstand tested at 1,000 VAC.
• Frequency Response: Stable contact for low-level signal paths.
• Sensitivity: Low contact resistance supports clean signals.
• Linearity: Consistent crimp interface across pins.
• Resolution: Fine pin spacing for dense 20-pin layouts.
• Temperature Range: -40 to 105°C for extreme sites.
• Environmental Resistance: 90% to 95% RH, non-condensing.
• Noise Immunity: High insulation blocks leakage paths.

Installation Notes

• Match the 20-pin male connector to the mating socket.
• Use crimp pins or receptacles for secure termination.
• Keep the square housing aligned before insertion.
• Check straight connection direction for cable routing.
• Avoid condensation during panel assembly.
• Confirm torque on crimp contacts before power-up.

Commissioning and Maintenance

• Test insulation resistance at 500 VDC before use.
• Measure contact resistance to confirm 5 milliohms or less.
• Inspect pins for bent or recessed contacts.
• Clean connector faces with approved contact cleaner.
• Re-check withstand voltage after any rework.
• Log humidity exposure for long-term records.

Compatibility

• Fits FANUC A02B series control interfaces.
• Works with HONDA 20-pin male mating sockets.
• Suits CNC, robot, and motion control panels.
• Supports legacy FANUC terminator requirements.
• Verify pinout and keying before replacement.

Certification and Quality

• Each kit passes insulation and contact checks.
• Withstand voltage test runs at 1,000 VAC for 1 minute.
• Units ship with a condition or test record.
• Oiltech Controls verifies parts before dispatch.
• Tested surplus and refurbished options available.

Packing List

• 1 x FANUC A02B-0047-C800 Terminator Kit
• 1 x 20-pin HONDA male connector
• 1 x Protective packing set
• 1 x Test record or condition note
• 1 x Order documentation

Warranty and Shipping

• 12-month warranty on eligible products.
• Dispatch within 24-28 hours after order confirmation.
• Shipping by FedEx, UPS, and DHL.
• Tracking provided after dispatch.
• Export-grade packing for small precision parts.

Typical Applications

• FANUC CNC control terminators
• Robot controller interface ends
• Motion control signal termination
• Legacy FANUC I/O panels
• Industrial harness end points

Diagnostic Capability

• Insulation faults show as low megaohm readings.
• High contact resistance points to worn crimp pins.
• Withstand voltage failures reveal insulation breakdown.
• Humidity damage appears as corrosion on contacts.
• Simple meter checks speed up fault isolation.

Oiltech Controls’s Insight

• Terminator kits often fail from bent pins, not electronics.
• Check mating socket keying before ordering a replacement.
• Store spare kits in dry, non-condensing cabinets.
• Crimp quality drives long-term contact resistance.
• Small parts like this are easy to overlook during audits.

Suitable Equipment

• FANUC CNC controls using A02B interfaces
• FANUC robot controllers with HONDA 20-pin ports
• Servo drive termination panels
• Legacy machine tools with obsolete connectors
• Industrial racks needing signal end termination

Why Buy From Oiltech Controls?

• Over 15 years in industrial automation spare parts.
• Global shipment support for urgent breakdowns.
• Tested industrial surplus and refurbished options.
• 12-month warranty on eligible products.
• Technical verification before every shipment.
• Support for obsolete control systems.
