Schneider Electric BMXAMO0802 – Modicon X80 Analog Output Module, 8 Channels
BMXAMO0802 is an 8-channel analog output module from the Modicon X80 series by Schneider Electric. It delivers configurable voltage and current signals for industrial control. The module fits M340 and M580 platforms. It supports group-to-group isolation and 12-bit resolution. Use it for precise analog output in demanding automation tasks.
Technical Specifications
| Brand | Schneider Electric |
| Model | BMXAMO0802 |
| Series | Modicon X80 |
| Module Type | Analog Output Module |
| Channels | 8 |
| Signal Type | Voltage / Current |
| Output Range | Configurable voltage and current |
| Resolution | 12-bit |
| Accuracy | ≤ 0.25% Full Scale |
| Isolation | Group-to-group |
| Diagnostics | Module status LED |
| Connection | 40-pin terminal block |
| Supply Voltage | 24 V DC via backplane |
| Power Consumption | 1.8 W |
| Bus Current | 74 mA @ 24 V DC |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Protection Rating | IP20 |
| Dimensions (H×W×D) | 100 × 28 × 93 mm |
| Weight | 0.17 kg |
| Lifecycle | Active (shared I/O for M340 and M580) — last verified 2026-09 |
Installation Guide
- Mount the module on a Modicon X80 backplane.
- Use a 40-pin terminal block for wiring.
- Connect voltage or current loads per channel.
- Keep group isolation intact for signal integrity.
- Verify 24 V DC supply from the backplane.
- Do not exceed IP20 environment limits.
Commissioning and Maintenance
- Check the module status LED after power-up.
- Configure output range in the PLC software.
- Use 12-bit resolution for fine control.
- Confirm accuracy is within 0.25% FS.
- Clean terminals only with dry methods.
- Replace module if diagnostics show faults.
Compatibility Notes
- Works with M340 and M580 PLC platforms.
- Shared I/O across both families.
- Requires standard X80 backplane slot.
- Supports group-to-group isolation.
- Use Schneider Electric terminal blocks.
- No external power supply needed beyond 24 V DC backplane.
Diagnostic Capabilities
- Module status LED shows health and faults.
- LED indicates channel or group errors.
- Supports quick visual checks in the field.
- No advanced software diagnostics on module.
- Use PLC programming tools for detailed status.
- Isolation helps prevent cross-channel noise.
Typical Applications
- Analog valve and actuator control.
- Variable frequency drive speed reference.
- Process control in water treatment.
- Chemical dosing and flow control.
- Factory automation signal conversion.
- Legacy M340 and M580 system upgrades.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipment support via FedEx, UPS, DHL.
- Tested industrial surplus and refurbished options.
- 12-month warranty on every module.
- Technical verification before shipment.
- Support for obsolete control systems.
FAQ
Q: Is the BMXAMO0802 new or refurbished?
A: We offer tested surplus and refurbished units. Each is verified before shipping.
Q: Does it work with M580?
A: Yes. It is shared I/O for M340 and M580.
Q: What is the warranty?
A: 12 months from Oiltech Controls.
Q: How fast is shipping?
A: We ship by FedEx, UPS, or DHL. Lead time varies by stock.
Q: Can I get technical help?
A: Yes. Contact us at info@oiltechcontrols.com or +86 158 8020 0923.
Package List and Warranty
- 1 × BMXAMO0802 module.
- 1 × quick start guide (digital).
- 12-month warranty included.
- Shipping via FedEx, UPS, DHL.
- Technical verification before dispatch.
- Packaging meets IP20 handling needs.
Certifications: CE, UL, RoHS (typical for Modicon X80 series). Confirm with factory label.
Contact Inquiries: info@oiltechcontrols.com | +86 158 8020 0923
