TM258LD42DR Schneider Electric Modicon M258 Compact Logic Controller
The TM258LD42DR belongs to the Schneider Electric Modicon M258 series. It is a compact logic controller with 42 I/O, mixed relay and transistor outputs, and a 24 VDC supply. A dual-core ARM Cortex-A8 processor separates program tasks and communication tasks. This design keeps control and network traffic stable under heavy load.
This controller fits machine control, production lines, and distributed automation. It offers Ethernet, CANopen, RS-485, and USB ports. Two free PCI slots accept communication or function modules. Up to seven TM5 or TM2 expansion modules can extend I/O to 2400 points.
Need a hard-to-find controller? Contact us at info@oiltechcontrols.com or +86 158 8020 0923. We test before shipment and support obsolete systems.
Technical Specifications
| Brand | Schneider Electric |
| Model | TM258LD42DR |
| Series | Modicon M258 |
| Module Type | Compact Logic Controller |
| Processor | Dual-core ARM Cortex-A8 |
| Core Task Split | Core1 for program tasks; Core2 for communication tasks |
| Program Memory | 128 K instructions |
| Data Memory | 64 MB RAM internal; 128 MB Flash |
| Scan Speed | 0.022 µs per Boolean instruction; over 45,000 Boolean instructions per ms |
| Digital Inputs | 26 total: 18 regular 24 Vdc plus 8 fast HSC 100 kHz |
| Digital Outputs | 16 total: 4 fast transistor 0.1 A plus 12 relay 2 A |
| Analog Inputs | None |
| Analog Outputs | None |
| High-Speed Counters | 8 × 100 kHz |
| Pulse Outputs | 4 fast reflex outputs |
| Expansion Modules | Up to 7 TM5 or TM2 modules; max 2400 I/O |
| Built-in Ports | 1× Ethernet RJ45; 1× CANopen SUB-D9; 1× RS-485; 1× USB-B mini |
| Protocols | Modbus TCP; CANopen master; Modbus RTU or ASCII; USB programming protocol |
| Communication Expansion | 2 free PCI slots for optional communication or function modules |
| Supply Voltage | 24 V DC; range 19.2 to 28.8 V |
| Power Consumption | 17.22 W |
| Bus Current | Not applicable; self-powered 24 V DC controller; no backplane bus |
| Operating Temperature | 0 to +55 °C; 0 to +60 °C with derating |
| Storage Temperature | -25 to +70 °C |
| Relative Humidity | 10 to 95%, non-condensing |
| Protection Rating | IP20 |
| Dimensions | 99 × 265 × 75 mm |
| Weight | 0.5 kg |
| Programming Software | SoMachine / EcoStruxure Machine Expert |
| Lifecycle Status | Active; last verified 2026-09 |
Note: The TM258LD42DR has no analog I/O. Use TM5 or TM2 expansion modules for analog signals. The dual-core CPU helps keep scan time stable when Ethernet and CANopen traffic rise.
Installation Guide
- Mount the controller on a DIN rail or panel. Keep IP20 protection in mind.
- Use a 24 VDC supply within 19.2 to 28.8 V.
- Allow airflow around the 99 × 265 × 75 mm housing.
- Keep high-voltage cables away from signal cables.
- Connect Ethernet, CANopen, RS-485, and USB before power-up.
- Use shielded cables for CANopen and RS-485.
- Check grounding to reduce noise on fast inputs and outputs.
Debugging and Maintenance
- Use SoMachine or EcoStruxure Machine Expert for online diagnostics.
- Check LED status for power, I/O, and communication faults.
- Monitor scan load with the built-in scan speed data.
- Back up programs and parameters before changes.
- Clean the housing with a dry cloth. Do not use solvents.
- Verify relay output life in high-cycle applications.
- Replace modules only after power is off.
Compatibility
- Works with Modicon M258 programming tools.
- Accepts up to 7 TM5 or TM2 expansion modules.
- Supports Modbus TCP, CANopen master, and Modbus RTU/ASCII.
- Two PCI slots allow extra communication or function modules.
- Fits existing M258 control cabinets and wiring schemes.
- No backplane bus; the controller uses its own 24 VDC supply.
Certifications and Compliance
- CE marking for European industrial use.
- UL/cUL listed for industrial control equipment.
- RoHS compliant.
- Designed for IP20 indoor environments.
- Meets common EMC requirements for industrial automation.
- Check local rules for final installation approval.
Packing List
- 1× TM258LD42DR controller
- 1× quick start guide
- 1× terminal block set
- 1× protective packaging
Warranty and Shipping
Each unit comes with a 12-month warranty. We ship by FedEx, UPS, and DHL. Tracking is provided after dispatch.
Typical Applications
- Machine control and packaging lines
- Material handling and conveyor systems
- Assembly cells and production equipment
- Distributed I/O with Ethernet and CANopen
- Retrofit projects for obsolete control systems
- High-speed counting and pulse output tasks
Diagnostic Capabilities
- Online monitoring through EcoStruxure Machine Expert.
- LED indicators for power, I/O, and network status.
- Fast counter diagnostics for 8 × 100 kHz HSC channels.
- Communication fault detection on Ethernet, CANopen, and RS-485.
- Program backup and restore for faster recovery.
- Scan load checks to spot performance limits.
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipment support.
- Tested industrial surplus and refurbished options.
- 12-month warranty on eligible products.
- Technical verification before shipment.
- Support for obsolete control systems.
Questions? Email info@oiltechcontrols.com or message us on WhatsApp at +86 158 8020 0923.
FAQ
Q: Does the TM258LD42DR have analog inputs?
A: No. It has no analog I/O. Add TM5 or TM2 modules for analog signals.
Q: How many expansion modules can I use?
A: Up to 7 TM5 or TM2 modules, with a maximum of 2400 I/O.
Q: What software programs this controller?
A: Use SoMachine or EcoStruxure Machine Expert.
Q: What is the scan speed?
A: 0.022 µs per Boolean instruction, or over 45,000 Boolean instructions per ms.
Q: What ports are built in?
A: Ethernet RJ45, CANopen SUB-D9, RS-485, and USB-B mini.
Q: What is the warranty?
A: 12 months.
Q: How do you ship?
A: We ship by FedEx, UPS, and DHL.
