TCSESM083F23F0 – ConneXium Managed Switch
Product Overview
TCSESM083F23F0 is an Ethernet TCP/IP managed switch from the ConneXium series. It offers 8 copper ports (10BASE‑T/100BASE‑TX) for reliable industrial networking. This switch supports unlimited cascading and ring redundancy (up to 50 switches). Built for Transparent Ready architectures, it ensures deterministic communication in harsh factory environments.
Why Choose Oiltech Controls?
- 15+ years in industrial automation spare parts.
- Global shipment via FedEx, UPS, DHL.
- Tested surplus / refurbished options with 12‑month warranty.
- Technical verification before shipment.
- Support for obsolete control systems (e.g., Modicon Quantum).
Key Technical Data
- Brand: Schneider Electric / ConneXium
- Model: TCSESM083F23F0
- Ports: 8 x RJ45 (10/100BASE‑TX) copper
- Redundancy: RSTP, ring coupling, redundant power
- Supply voltage: 24 V DC (9.6…60 V DC SELV) or 18…30 V AC
- Power consumption: 5.3 W
- Operating temp: 0…60 °C
- Humidity: 10…95 % (non‑condensing)
- IP rating: IP20
- Mounting: 35 mm DIN rail
- Dimensions: 74 x 131 x 111 mm (W x H x D)
- Weight: 0.41 kg
Technical Specifications (Detailed)
| Protocol | Ethernet TCP/IP, Transparent Ready |
| Ethernet services | Web server, IGMP Snooping, VLAN, RSTP, SMTP V3, SNTP, priority port, secure port, multicast filtering |
| Ring capacity | Up to 50 switches in a ring |
| Alarm output | 1 volt‑free contact (1 A) for power, switch, link, ring fault |
| LED indicators | Fault, P1/P2, ring manager, standby, port activity/status |
| Standards | EN/IEC 61131‑2, UL 1604 Cl.1 Div.2, UL 508, CSA C22.2 No.213/214, GL, C‑Tick |
Installation & Diagnostics
- Mounting: 35 mm symmetrical DIN rail – quick clip‑on.
- Electrical connection: 6‑way removable terminal block for power.
- Diagnostic capabilities: Fault relay, port LEDs, ring manager LED, web‑based monitoring.
- Data flow control: FDR, IGMP Snooping, multicast filtering, priority port, RSTP.
- Compatibility: Works with Modicon Quantum and other Ethernet/IP devices.
Environmental & Certifications
- Ambient temp: 0…60 °C – reliable in control cabinets.
- Protection: IP20 (indoor use).
- Approvals: CE, UL 1604 Class 1 Div 2, UL 508, CSA 213/214, GL, C‑Tick.
- Resistance: Meets industrial EMC and shock/vibration standards.
Package & Warranty
- Included: Switch unit, 6‑way power connector, quick start guide.
- Warranty: 12 months against defects.
- Shipping: FedEx, UPS, DHL – worldwide express.
Typical Applications
- Factory automation networks (assembly lines, conveyors).
- Process control systems (oil & gas, water treatment).
- SCADA and remote I/O backbones.
- Ring‑redundant architectures for critical infrastructure.
FAQ – Quick Answers
- Q: Can I cascade unlimited switches?
Yes – unlimited cascading via copper ports. - Q: Max ring size?
50 switches with RSTP ring coupling. - Q: Power supply range?
9.6‑60 V DC or 18‑30 V AC (SELV). - Q: Does it support obsolete systems?
Yes, we verify compatibility with legacy Modicon Quantum and more.
