TM200C16R
Logic Controller – M200 16 IO Relay – Schneider Electric

Product Description

TM200C16R is a compact logic controller from the Easy Modicon M200 series.
It offers 16 discrete I/O with 7 relay outputs. The controller runs on 100…240 V AC supply.
It includes 4 high-speed inputs (up to 100 kHz) and 4 fast inputs.
This unit supports Modbus RTU/ASCII and USB programming.
It is ideal for small to medium automation tasks.

The TM200C16R works with up to 4 expansion modules. It provides PID regulation for up to 14 loops.
Built-in SD card slot (optional) backs up programs.
This controller suits conveyor systems, packaging machines, and pump control.

Technical Specifications

Key Features & Performance

• 100 kHz High-Speed Inputs – for precise counting and positioning
• Relay Outputs – 7 channels, 2 A each, 100k electrical cycles
• Built-in PID – 14 loops, adjustable, self-tuning
• Modbus RTU/ASCII – master/slave over RS232/RS485
• USB Programming – mini B port, 12 Mbit/s
• Expandable – up to 4 I/O expansion modules
• Fast Execution – 0.2 µs per Boolean instruction
• SD Card Backup – optional 32 GB for program storage

Environmental & Immunity

• Temp Range: 0…55°C operation, -25…70°C storage
• Humidity: 10-95% non-condensing
• EMC Immunity: 8 kV ESD, 10 V/m radiated, 2 kV burst (power), 2 kV surge (relay)
• Vibration: 3.5 mm (5-8.4 Hz), 1 gn (8.4-150 Hz) on rail
• Shock: 15 gn for 11 ms, 30 gn for 6 ms
• Pollution Degree: 2, suitable for industrial environments

Installation & Commissioning

• Mounting: DIN rail TH35-15 or panel with kit
• Wiring: removable screw terminals for I/O, power, serial
• Programming: via USB mini B or serial link
• Software: SoMachine-Network compatible
• Diagnostics: LED indicators for PWR, RUN, ERR, SD, BAT, SL1, I/O state

Compatibility & Certifications

• Standards: EN/IEC 61131-2, EN/IEC 61010-2-201
• Certifications: CSA, cULus, IACS E10, RCM, CE
• Expandable: with up to 4 M200 expansion modules
• Protocol: Modbus master/slave, ASCII/RTU

Package, Warranty & Shipping

• Included: TM200C16R controller, terminal blocks, mounting accessories
• Warranty: 12 months against defects
• Shipping: FedEx, UPS, DHL – global express
• Package Weight: 508 g, dimensions 13.7 x 12.3 x 9.6 cm

Typical Applications & Diagnostics

• Applications: conveyors, packaging, pump control, small machines, HVAC
• Diagnostic: LED status, error detection via SoMachine, battery low alert (BAT LED)
• Troubleshooting: real-time I/O monitoring, module error (ERR) LED

Frequently Asked Questions

• Q: Max expansion modules? A: Up to 4 modules (64 transistor or 71 relay outputs).
• Q: Battery life? A: 5 years typical, 3 years backup at 25°C.
• Q: High-speed inputs support? A: Quadrature, Pulse/Dir, Single, CW/CCW at 100 kHz.
• Q: Programming software? A: SoMachine-Network via USB or serial.
