A02B-0072-C204 FANUC Connector Panel – 7x 25-Pin D-Sub Male, NEMA 1, Panel Mount
The A02B-0072-C204 is a FANUC connector panel for industrial interfacing. It carries seven standard 25-pin D-sub male connectors. This layout supports multi-device wiring in one compact plate. The unit mounts directly to a cabinet panel. As a result, it saves space and simplifies cable routing.
Technical Specifications
- Brand: FANUC
- Model: A02B-0072-C204
- Series: A02B
- Product Type: Connector Panel
- Weight: 0.57 kg (1.25 lbs)
- Mount Type: Panel Mounted
- Number of Connectors: 7
- Connector Type: 25-pin D-sub Male
- Enclosure Rating: NEMA 1
- Cooling: Natural
- Max Ambient Temperature: 40°C
- Min Ambient Temperature: 0°C
- Max Operating Humidity: 80% non-condensing
- Max Storage Humidity: 80% non-condensing
- Max Operating Altitude: 1000 m above sea level
Series Insight
- The A02B line covers FANUC panel and connection hardware.
- These parts link CNC controllers to drives and I/O devices.
- Engineers use them to rebuild or expand legacy cabinets.
- Pinouts follow FANUC factory standards for drop-in fit.
- NEMA 1 suits indoor, dust-light control rooms.
Compatible Equipment
- FANUC CNC control cabinets
- Servo and spindle amplifier racks
- I/O unit connection panels
- Legacy FANUC machine tool interfaces
- Custom industrial control enclosures
Oiltech Controls Review
- This panel is a simple, rugged interconnect part.
- Seven D-sub ports reduce separate breakout boards.
- Panel mounting gives strong mechanical support.
- Natural cooling means no fan maintenance.
- It fits older FANUC systems where parts are scarce.
Why Buy From Oiltech Controls?
- Over 15 years in industrial automation spare parts.
- Worldwide shipping with tracking on every order.
- Tested surplus and refurbished options available.
- Each unit carries a 12-month warranty.
- We verify technical condition before shipment.
- We support obsolete control systems.
Warranty and Shipping
- 12-month warranty covers this product.
- Orders ship within 24 to 28 hours.
- Carriers: FedEx, UPS, DHL.
- Tracking number sent after dispatch.
FAQ
Q: Does this panel replace a damaged FANUC connector plate?
A: Yes. It matches the A02B footprint. Check your old part number first.
Q: Can I use it with a non-FANUC CNC?
A: Only if your wiring matches the 25-pin D-sub pinout. Otherwise, signal mapping may fail.
Q: How many devices can I connect at once?
A: You get seven separate ports. Each port handles one 25-pin cable.
Q: Is this unit new or refurbished?
A: We stock both tested surplus and refurbished units. Ask us for current condition.
Q: What should I check before ordering?
A: Confirm connector gender, pin count, and panel cutout size. Also verify your cabinet depth.
