IC200MDL743 Discrete Output Module – Versamax Series
The IC200MDL743 is a 16-point negative logic DC output module from the GE Fanuc Versamax series. It delivers 5, 12, or 24 VDC sinking outputs rated at 0.5 A per point. This module supports hot insertion and automatic I/O addressing for simplified installation. It directly interfaces with the backplane and requires an external power supply for loads. Typical applications include driving relays, lights, and motor starters in PLC-based control systems.
Technical Specifications
| Brand | GE Fanuc |
| Model | IC200MDL743 |
| Series | Versamax |
| Outputs | 16 sinking, 1 group (non-isolated) |
| Voltage (5V TTL) | 4.75 – 5.25 VDC (nominal 5V) |
| Voltage (12/24V) | 10.2 – 30 VDC (nominal 12/24V) |
| Output Current | 0.5 A per point (max) |
| Leakage Current | 0.5 mA @ 30 VDC |
| Response Time (On) | 0.2 ms |
| Response Time (Off) | 1.0 ms |
| Backplane Current | 70 mA @ 5 VDC |
| External Supply | Required (10.2 – 30 VDC) |
| Isolation | None (group-to-group / point-to-point) |
| LED Indicators | Per point, OK, FLD PWR |
| Module ID | FFFF8080 |
Key Features & Benefits
- Negative logic sinking outputs switch the load to DC common.
- Wide voltage range (5/12/24 VDC) supports diverse field devices.
- Compact design saves panel space and simplifies wiring.
- Hot-swappable for maintenance without system shutdown.
- Automatic addressing reduces setup time in PLC systems.
- LED status for each output and power/OK indicators.
- No internal fuse – use external overcurrent protection.
Installation & Wiring
- Mount on standard Versamax carriers (box or spring style).
- Connect external 10.2–30 VDC supply to FLD PWR terminals.
- Separate power, control, and signal wiring to reduce noise.
- Insert module into rack with power off or use hot insertion.
- Use twisted shielded cables for long runs.
Environmental & Certifications
- Operating temperature: 0 to 60 °C
- Storage temperature: -40 to 85 °C
- Humidity: 5–95% RH (non-condensing)
- Shock & vibration: IEC 60068-2-6, IEC 60068-2-27
- EMC: EN 61000-6-2, EN 61000-6-4
- Certifications: CE, UL, CSA (check specific ratings)
Diagnostics & LED Indications
- Per-point LEDs show output state (on/off).
- OK LED indicates module health and backplane communication.
- FLD PWR LED confirms external supply presence.
- No point-to-point isolation – use external diagnostic relays if needed.
Compatibility
- Works with Modicon Quantum and other PLCs via Versamax backplane.
- Supports GE Fanuc controllers with 5/12/24 VDC output groups.
- No group isolation – ensure proper load sharing.
Package Contents
- 1 x IC200MDL743 Output Module
- Carrier (optional, order separately)
- User manual (digital download)
Warranty & Shipping
- 12-month warranty against defects.
- Shipped via FedEx, UPS, or DHL (global tracking).
- All units tested before shipment.
Frequently Asked Questions (FAQ)
Q: Can I use this with 24V AC loads?
A: No, it is DC only (10.2–30 VDC).
Q: Does it have internal fuses?
A: No, use external fusing per output.
Q: What is the output leakage current?
A: 0.5 mA at 30 VDC – acceptable for most loads.
Q: Is this module isolated from the backplane?
A: No, it shares common with the backplane.
Q: Can I replace it while the system is running?
A: Yes, it supports hot insertion (carefully).
