iC60H 2P C20 Schneider Electric Acti9 Miniature Circuit Breaker
Model: iC60H 2P C20
Brand: Schneider Electric
Series: Acti9 iC60
The iC60H 2P C20 is a 2-pole miniature circuit breaker from the Acti9 iC60 range. It protects circuits against overload and short circuit. The C-curve trips at 8 x In ±20%. It suits resistive and inductive loads. Breaking capacity reaches 10 kA at 230/400 V. It complies with IEC 60898-1 and IEC 60947-2. The unit mounts on 35 mm DIN rail. It is ideal for industrial panels, building distribution, and OEM machines.
Technical Specifications
| Brand | Schneider Electric |
| Model | iC60H 2P C20 |
| Series | Acti9 iC60 |
| Module Type | Miniature Circuit Breaker (MCB) |
| Poles | 2P |
| Rated Current | 20 A |
| Trip Curve | C (thermal-magnetic) |
| Magnetic Trip | 8 x In ±20% |
| Breaking Capacity | 10 kA @ 230/400 V |
| Rated Voltage | 400 V AC, 125 V DC |
| Frequency | 50/60 Hz |
| Measurement Range | 0 to 20 A rated current |
| Sensitivity | Overload and short-circuit detection |
| Linearity | Stable thermal-magnetic response |
| Resolution | 1 A step rating |
| Temperature Range | -35 to 70 °C |
| Environmental Resistance | Industrial indoor use |
| Interference Immunity | Meets IEC 60898-1 |
| Mounting | 35 mm DIN rail |
| Mechanical Life | 20,000 cycles |
| Electrical Life | 10,000 cycles |
| Dimensions | 85 x 36 x 78.5 mm |
| Weight | 0.25 kg |
Installation Guide
- Mount on 35 mm DIN rail.
- Keep panel clean and dry.
- Tighten terminals to specified torque.
- Use correct cable size for 20 A.
- Do not exceed 400 V AC.
Setup and Maintenance
- Check trip curve before installation.
- Test manual switching after wiring.
- Inspect terminals every 6 months.
- Replace after 10,000 electrical cycles.
- Clean with dry cloth only.
Compatibility
- Fits Acti9 iC60 accessories.
- Works with standard DIN enclosures.
- Compatible with Schneider busbars.
- Replaces many obsolete MCBs.
Certifications
- EN/IEC 60898-1
- EN/IEC 60947-2
- CE marked
- RoHS compliant
Packing List
- 1 x iC60H 2P C20 breaker
- 1 x datasheet copy
- 1 x protective box
Warranty and Shipping
All units include a 12-month warranty. We ship by FedEx, UPS, and DHL. Tracking is provided. Packing is rugged for global transit.
Typical Applications
- Industrial control panels
- Building distribution boards
- OEM machinery
- HVAC systems
- Pump and motor circuits
Diagnostic Capability
- Visual trip indicator
- Manual ON/OFF test
- Thermal overload response
- Magnetic short-circuit response
Why Buy From Oiltech Controls?
- 15+ years in industrial automation spare parts
- Global shipment support
- Tested industrial surplus and refurbished options
- 12-month warranty
- Technical verification before shipment
- Support for obsolete control systems
