SR3B261FU Schneider Zelio Logic Smart Relay 26 I/O
Model: SR3B261FU
Brand: Schneider Electric
Series: Zelio Logic
The SR3B261FU is a modular smart relay from the Schneider Zelio Logic range. It packs 26 I/O points into a compact DIN rail housing. The controller runs on 100-240 V AC supply. It includes 16 digital inputs, with 6 configurable as analog. It offers 10 relay outputs rated 5 A each. An integrated real-time clock handles time-based logic. The LCD screen and navigation buttons allow on-site programming and monitoring. This relay suits small automation tasks that replace traditional relay panels.
Technical Data
- Model: SR3B261FU
- Brand: Schneider Electric
- Series: Zelio Logic
- I/O points: 26
- Digital inputs: 16, 6 analog-capable, 100-240 V AC
- Digital outputs: 10 relay, 5 A per output
- Supply: 100-240 V AC, 85-264 V, 50/60 Hz
- Clock: Integrated real-time clock
- Display: LCD with navigation buttons
- Communication: via extension modules
- Program memory: 240 lines ladder or 500 blocks FBD
- Operating temperature: -20 to 55 °C
- Mounting: 35 mm DIN rail
- Dimensions: 90 x 124.6 x 59.5 mm
- Weight: 0.30 kg
- Mechanical life: 10,000,000 cycles
- Electrical life: 500,000 cycles, AC-12, 230 V 1.5 A, IEC 60947-5-1
Oiltech Controls’s Insight
- The SR3B261FU bridges relay logic and PLC control.
- Good fit when a full PLC is overkill.
- Ladder and FBD support ease commissioning.
- The real-time clock enables scheduling tasks.
- Analog-capable inputs reduce extra modules.
- Relay outputs handle mixed AC loads.
Suitable Equipment
- Small conveyor and packaging machines
- Pumping and lighting control panels
- HVAC and building automation units
- Gate, door, and access control systems
- Water treatment and irrigation skids
- Retrofit of obsolete relay logic
Why Buy From Oiltech Controls?
- Over 15 years in industrial automation spare parts
- Worldwide shipping through FedEx, UPS, and DHL
- Tested industrial surplus and refurbished options
- 12-month warranty on every unit
- Technical verification before shipment
- Support for obsolete control systems
- Dispatch in 24-28 hours
Warranty and Shipping
- 12-month warranty included
- Ships in 24-28 hours
- FedEx, UPS, and DHL options
- Tracking sent after dispatch
FAQ
Q: Can the SR3B261FU replace a small PLC?
A: Yes, for logic, timing, and relay tasks. It lacks advanced motion control. Choose a PLC when you need high-speed counters or PID loops.
Q: How do I program this smart relay?
A: Use the built-in LCD and buttons for simple edits. For full programs, use Zelio Soft with ladder or FBD. The 240-line ladder memory covers most small jobs.
Q: What loads can the relay outputs drive?
A: Each output handles 5 A. They suit contactors, lamps, and small motors. Add interposing relays for high inrush loads. Check AC-12 ratings for inductive loads.
Q: Should I pick the SR3B261FU or a Zelio Logic with more I/O?
A: Count your inputs and outputs first. This model gives 26 I/O. If you need more points, step up the range or add extension modules. Analog needs may also push you to a larger unit.
Q: How do I verify a surplus or refurbished unit?
A: Ask for test reports and firmware version. Confirm the display and relay outputs work. Oiltech Controls checks each unit before shipment and backs it with a 12-month warranty.
